— 99 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
TRANSISTOR
Q621
!
8-729-044-30 TRANSISTOR 2SK2845-LB102
Q622 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q623 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q624 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q644 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q645 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q646 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q647 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q648 8-729-922-39 TRANSISTOR 2SD2144S-V
Q649 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q650 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q651 8-729-802-71 TRANSISTOR 2SA1407-E
Q652 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q653 8-729-119-78 TRANSISTOR 2SC2785-HFE
RESISTOR
R601
!
1-249-377-11 CARBON 0.47 5% 1/4W F
R602 1-249-429-11 CARBON 10K 5% 1/4W
R603
!
1-219-776-11 CARBON 2.2M 10% 1/2W
R604 1-249-429-11 CARBON 10K 5% 1/4W
R605 1-249-429-11 CARBON 10K 5% 1/4W
R606 1-249-421-11 CARBON 2.2K 5% 1/4W
R607
!
1-202-933-61 FUSIBLE 0.1 10% 1/2W F
R608 1-216-369-00 METAL OXIDE 1 5% 2W F
R609 1-249-417-11 CARBON 1K 5% 1/4W
R610 1-249-425-11 CARBON 4.7K 5% 1/4W
R611 1-216-369-00 METAL OXIDE 1 5% 2W F
R612 1-260-124-11 CARBON 120K 5% 1/2W
R613 1-260-124-11 CARBON 120K 5% 1/2W
R614 1-260-124-11 CARBON 120K 5% 1/2W
R615 1-260-124-11 CARBON 120K 5% 1/2W
R618 1-249-425-11 CARBON 4.7K 5% 1/4W
R619 1-249-425-11 CARBON 4.7K 5% 1/4W
R620 1-126-967-11 ELECT 47µF 20% 50V
R621 1-249-429-11 CARBON 10K 5% 1/4W
R622 1-247-863-91 CARBON 22K 5% 1/4W
R623
!
1-240-257-11 CMT,MELF 3.9 5% 20W
R624
!
1-215-485-00 METAL 470K 1% 1/4W
R625
!
1-215-485-00 METAL 470K 1% 1/4W
R626 1-249-425-11 CARBON 4.7K 5% 1/4W
R627 1-249-405-11 CARBON 100 5% 1/4W F
R631 1-240-205-91 CARBON 22M 5% 1/2W
R632 1-249-421-11 CARBON 2.2K 5% 1/4W
R633 1-249-429-11 CARBON 10K 5% 1/4W
R634 1-249-437-11 CARBON 47K 5% 1/4W
R635 1-247-791-91 CARBON 22 5% 1/4W
R636 1-249-415-11 CARBON 680 5% 1/4W
R637 1-260-302-51 CARBON 6.8 5% 1/2W
R638 1-249-413-11 CARBON 470 5% 1/4W
R639
!
1-249-389-11 CARBON 4.7 5% 1/4W F
R640 1-215-485-00 METAL 470K 1% 1/4W
R641 1-247-843-11 CARBON 3.3K 5% 1/4W
R642 1-247-843-11 CARBON 3.3K 5% 1/4W
R643 1-249-387-11 CARBON 3.3 5% 1/2W F
R644 1-249-417-11 CARBON 1K 5% 1/4W
R645 1-249-429-11 CARBON 10K 5% 1/4W
R646 1-249-417-11 CARBON 1K 5% 1/4W
R648 1-249-441-11 CARBON 100K 5% 1/4W
R649 1-249-425-11 CARBON 4.7K 5% 1/4W F
R650 1-249-421-11 CARBON 2.2K 5% 1/4W
R651 1-215-908-00 METAL OXIDE 33 5% 3W F
R652
!
1-216-363-00 METAL OXIDE 0.33 5% 2W F
R653 1-215-423-00 METAL 1.2K 1% 1/4W
R654 1-215-481-00 METAL 330K 1% 1/4W
R655 1-215-469-00 METAL 100K 1% 1/4W
R656 1-249-427-11 CARBON 6.8K 5% 1/4W
R657 1-249-421-11 CARBON 2.2K 5% 1/4W
R659 1-249-429-11 CARBON 10K 5% 1/4W
R660 1-249-393-11 CARBON 10 5% 1/4W F
R661
!
1-249-419-11 CARBON 1.5K 5% 1/4W F
R662 1-215-485-00 METAL 470K 1% 1/4W
R663 1-215-445-00 METAL 10K 1% 1/4W
R664
!
1-240-257-11 CMT,MELF 3.9 5% 20W
R665 1-249-425-11 CARBON 4.7K 5% 1/4W
R670 1-260-312-11 CARBON 47 5% 1/2W
R671 1-260-312-11 CARBON 47 5% 1/2W
R680 1-216-364-11 METAL OXIDE 0.39 5% 2W F
R681 1-216-365-00 METAL OXIDE 0.47 5% 2W F
R699 1-249-429-11 CARBON 10K 5% 1/4W
RELAY
RY600
!
1-755-266-11 RELAY, AC POWER
RY601
!
1-755-146-11 RELAY, AC POWER
TRANSFORMER
T601
!
1-426-717-11 TRANSFORMER, LINE FILTER (LFT)
T602
!
1-426-717-11 TRANSFORMER, LINE FILTER (LFT)
T603
!
1-429-992-21 TRANSFORMER, CONVERTER (PRT)
T605
!
1-433-408-11 TRANSFORMER, CONVERTER (PIT)
T621
!
1-431-852-11 TRANSFORMER, CONVERTER (SRT)
THERMISTOR
THP601
!
1-809-539-11 THERMISTOR, POSITIVE
THP602
!
1-809-539-11 THERMISTOR, POSITIVE
VARISTOR
VDR601
!
1-801-074-41 VARISTOR ERZV10D271
VDR602
!
1-801-074-41 VARISTOR ERZV10D271
