— 120 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
TRANSISTOR
Q3301 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3302 8-729-216-22 TRANSISTOR 2SA1162-G
Q3305 8-729-216-22 TRANSISTOR 2SA1162-G
Q3306 8-729-216-22 TRANSISTOR 2SA1162-G
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
Q3307 8-729-216-22 TRANSISTOR 2SA1162-G
Q3310 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3312 8-729-216-22 TRANSISTOR 2SA1162-G
Q3314 8-729-216-22 TRANSISTOR 2SA1162-G
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
Q3322 8-729-422-27 TRANSISTOR 2SD601A-Q
(KV-32FV15/36FV15 only)
RESISTOR
R3301 1-216-295-91 SHORT
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R3303 1-216-295-91 SHORT
R3304 1-216-295-91 SHORT
R3305 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R3306 1-216-295-91 SHORT
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R3308 1-216-295-91 SHORT
(KV-32FV15/36FV15 only)
R3309 1-216-041-00 RES, CHIP 470 5% 1/10W
R3312 1-216-037-00 RES, CHIP 330 5% 1/10W
R3313 1-216-295-91 SHORT
R3314 1-216-049-91 RES, CHIP 1K 5% 1/10W
R3320 1-216-295-91 SHORT
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R3322 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R3322 1-216-295-91 SHORT
(KV-32FS10/34FV10/36FS10 only)
R3323 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R3323 1-216-295-91 SHORT
(KV-32FS10/34FV10/36FS10 only)
R3324 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R3324 1-216-295-91 SHORT
(KV-32FS10/34FV10/36FS10 only)
R3325 1-216-025-91 RES, CHIP 100 5% 1/10W
(KV-32FV15/36FV15 only)
R3326 1-216-295-91 SHORT
R3329 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
R3332 1-216-033-00 RES, CHIP 220 5% 1/10W
R3337 1-216-033-00 RES, CHIP 220 5% 1/10W
R3338 1-216-033-00 RES, CHIP 220 5% 1/10W
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R3339 1-216-049-91 RES, CHIP 1K 5% 1/10W
R3340 1-216-041-00 RES, CHIP 470 5% 1/10W
R3341 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R3342 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R3343 1-216-049-91 RES, CHIP 1K 5% 1/10W
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R3346 1-216-049-91 RES, CHIP 1K 5% 1/10W
R3350 1-216-295-91 SHORT
R3351 1-216-295-91 SHORT
R3352 1-216-049-91 RES, CHIP 1K 5% 1/10W
R3355 1-216-295-91 SHORT
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R3357 1-216-295-91 SHORT
R3358 1-216-047-91 RES, CHIP 820 5% 1/10W
R3359 1-216-047-91 RES, CHIP 820 5% 1/10W
R3360 1-216-053-00 RES, CHIP 1.5K 5% 1/10W
R3361 1-216-045-00 RES, CHIP 680 5% 1/10W
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R3362 1-208-768-11 RES, CHIP 240 0.50% 1/10W
R3363 1-208-766-11 RES, CHIP 220 0.50% 1/10W
R3364 1-208-769-11 RES, CHIP 300 0.50% 1/10W
R3370 1-216-295-91 SHORT
R3375 1-216-041-00 RES, CHIP 470 5% 1/10W
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R3376 1-216-071-00 RES, CHIP 8.2K 5% 1/10W
R3377 1-216-073-00 RES, CHIP 10K 5% 1/10W
R3378 1-216-053-00 RES, CHIP 1.5K 5% 1/10W
R3379 1-216-077-00 RES, CHIP 15K 5% 1/10W
R3380 1-216-295-91 SHORT
R3381 1-216-295-91 SHORT
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R3382 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R3383 1-216-025-91 RES, CHIP 100 5% 1/10W
R3384 1-216-033-00 RES, CHIP 220 5% 1/10W
R3385 1-216-109-00 RES, CHIP 330K 5% 1/10W
R3387 1-216-295-91 SHORT
R3388 1-216-295-91 SHORT
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R3392 1-216-295-91 SHORT
R3393 1-216-025-91 RES, CHIP 100 5% 1/10W
R3394 1-216-041-00 RES, CHIP 470 5% 1/10W
(KV-32FV15/36FV15 only)
R3395 1-216-061-91 RES, CHIP 3.3K 5% 1/10W
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
R3398 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
R3399 1-216-025-91 RES, CHIP 100 5% 1/10W
R3401 1-216-025-91 RES, CHIP 100 5% 1/10W
R3402 1-216-025-91 RES, CHIP 100 5% 1/10W
R3404 1-216-073-00 RES, CHIP 10K 5% 1/10W
(KV-32FV15/36FV15 only)
CRYSTAL
X3302 1-760-095-21 VIBRATOR, CRYSTAL
X3303 1-577-611-11 OSCILLATOR CERAMIC
X3304 1-567-505-11 OSCILLATOR CRYSTAL
(KV-32FV15/36FV15/34FV15/34FV15C/34FV15K/34FV15T/38FV15K only)
