REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
COMPLETE PARTS LISTING
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K/
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
* A-1394-934-A T BOARD, COMPLETE
(KV32XBR250/34FX250C/36XBR250/38FX250/38FX250C/38FX250T only)
CAPACITOR
C401 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C402 1-163-035-00 CERAMIC CHIP 0.047µF 50V
C403 1-126-963-11 ELECT 4.7µF 20% 50V
C404 1-163-135-00 CERAMIC CHIP 560pF 5% 50V
C405 1-104-664-11 ELECT 47µF 20% 25V
C406 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C407 1-163-035-00 CERAMIC CHIP 0.047µF 50V
C408 1-163-135-00 CERAMIC CHIP 560pF 5% 50V
C409 1-126-963-11 ELECT 4.7µF 20% 50V
C410 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C411 1-126-963-11 ELECT 4.7µF 20% 50V
C412 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C413 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C414 1-104-664-11 ELECT 47µF 20% 25V
C415 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C416 1-104-664-11 ELECT 47µF 20% 25V
C417 1-126-963-11 ELECT 4.7µF 20% 50V
C418 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C419 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
C420 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C421 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C422 1-104-664-11 ELECT 47µF 20% 25V
C423 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C424 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C425 1-104-664-11 ELECT 47µF 20% 25V
C426 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
CONNECTOR
CN401 *1-564-519-11 PLUG, CONNECTOR 4P
DIODE
D401 8-719-109-89 DIODE RD5.6ESB2
D402 8-719-057-93 DIODE SVC203SPA-AL
D403 8-719-057-93 DIODE SVC203SPA-AL
D404 8-719-992-13 DIODE DAL5815
D405 8-719-992-13 DIODE DAL5815
D406 8-719-992-13 DIODE DAL5815
D407 8-719-992-13 DIODE DAL5815
D408 8-719-992-13 DIODE DAL5815
D409 8-719-992-13 DIODE DAL5815
D410 8-719-992-13 DIODE DAL5815
D411 8-719-992-13 DIODE DAL5815
TT
IC
IC401 8-759-939-73 IC BA3308
COIL
L401 1-411-987-11 COIL (OSC)
L402 1-411-988-11 COIL (OSC)
TRANSISTOR
Q401 8-729-266-83 TRANSISTOR 2SC2668-Y
Q402 8-729-266-83 TRANSISTOR 2SC2668-Y
Q403 8-729-119-78 TRANSISTOR 2SC3311A-QRSTA
Q404 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q405 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q406 8-729-931-14 TRANSISTOR 2SD1858-Q-TV2
Q407 8-729-931-14 TRANSISTOR 2SD1858-Q-TV2
Q408 8-729-931-14 TRANSISTOR 2SD1858-Q-TV2
Q409 8-729-931-14 TRANSISTOR 2SD1858-Q-TV2
Q410 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q411 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
RESISTOR
R401 1-216-089-91 RES, CHIP 47K 5% 1/10W
R402 1-216-089-91 RES, CHIP 47K 5% 1/10W
R403 1-216-089-91 RES, CHIP 47K 5% 1/10W
R404 1-216-053-00 RES, CHIP 1.5K 5% 1/10W
R405 1-216-025-91 RES, CHIP 100 5% 1/10W
R406 1-216-053-00 RES, CHIP 1.5K 5% 1/10W
R407 1-216-133-00 RES, CHIP 3.3M 5% 1/10W
R408 1-216-089-91 RES, CHIP 47K 5% 1/10W
R409 1-216-053-00 RES, CHIP 1.5K 5% 1/10W
R410 1-216-053-00 RES, CHIP 1.5K 5% 1/10W
R411 1-216-025-91 RES, CHIP 100 5% 1/10W
R412 1-208-803-11 RES, CHIP 7.5K 0.50% 1/10W
R413 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R414 1-216-073-00 RES, CHIP 10K 5% 1/10W
R415 1-249-416-11 CARBON 820 5% 1/4W
R416 1-216-081-00 RES, CHIP 22K 5% 1/10W
R417 1-216-081-00 RES, CHIP 22K 5% 1/10W
R418 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R419 1-216-073-00 RES, CHIP 10K 5% 1/10W
R420 1-216-111-00 RES, CHIP 390K 5% 1/10W
R421 1-216-025-91 RES, CHIP 100 5% 1/10W
R422 1-216-025-91 RES, CHIP 100 5% 1/10W
R423 1-216-111-00 RES, CHIP 390K 5% 1/10W
R424 1-216-053-00 RES, CHIP 1.5K 5% 1/10W
R425 1-216-061-00 RES, CHIP 3.3K 5% 1/10W
R426 1-208-821-11 RES, CHIP 43K 0.50% 1/10W
R427 1-216-061-00 RES, CHIP 3.3K 5% 1/10W
R428 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R429 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
T
To Next Page
