12 (GB)
Video signal
Frequency response
LINE 8 MHz +0 dB, –6 dB (Y signal)
Picture performance
Normal scan 7 % over scan of CRT effective
screen area
H. linearity Less than 8.0 % (typical)
V. linearity Less than 7.0 % (typical)
Color temperature D65, D93, USER (Adjustable color
temperature: 5000 K to 10000 K)
Resolution 600 TV lines (When Y/C signal is
inputted)
Input connectors
LINE A/B input connector
Y/C input 4-pin mini-DIN (×2)
See the pin assignment on the page
13 (GB).
VIDEO input BNC connector (×2), 1Vp-p +3 dB,
–6 dB, negative synchronization
AUDIO input
Phono jack (×2), –5 dBu
a)
, 47 kΩ or
higher
Output connectors
LINE A output connecters
Y/C output 4-pin mini-DIN (×1) Loop-through,
75 Ω automatic terminal function
VIDEO output
BNC type (×1) Loop-through, 75 Ω
automatic terminal function
AUDIO output
Phono jack (×1) Loop-through
Built-in speaker output
0.8 W (monaural)
Specifications
a) 0 dBu = 0.775 Vr.m.s.
........................................................................................................................................................................................................
General
CRT Trinitron P22 luminescent material
Power consumption
68 W, 1.1 to 0.4A
Power requirement
100 to 240 V AC, 50/60Hz
Peak inrush current
(1)Power ON, current probe
method: 93 A (240 V)
(2)Hot switching inrush current,
measured in accordance with
European standard EN55103-1:
42 A (230 V)
Operating conditions
Temperature 0 to +40°C (32°F to 104°F)
Humidity 30 to 85% (no condensation)
Pressure 700 hPa to 1060 hPa
Storage and transport conditions
Temperature –10 to +40°C (14°F to 104°F)
Humidity 0 to 90%
Pressure 700 hPa to 1060 hPa
Dimensions (w/h/d)
Approx. 346 × 340 × 414 mm
(13
5
⁄8 × 13
1
⁄2 × 16
3
⁄8 inches)
Mass Approx. 15 kg (33 lb 2 oz)
Accesory supplied AC power cord (1)
Side covers (2)
Operating Instructions (1)
Design and specifications are subject to change
without notice.
