Sony Trinitron PVM-14N1E Service Manual

Menu operation buttons
There are four menu operation buttons on the front
panel of the monitor.
© ENTER button
B® t button
# button
Button functions depend on the displayed menu. The
following table shows the button functions on the item
selection menus and adjustment and setting menus.
MENU/EXIT | To return to the To return to the
reguiar screen. item selection
menu.
To move the To decrease
cursor downward. } value/select item.
To move the
cursor upward.
Ot
To increase
value/select item.
To decide a
selected item.
© ENTER To decide a
selected item®.
a) You can use the ENTER button only on the{2d]USER
MEMORY menu of the adjustment and setting menus.
Usable buttons depend on the displayed menu. Buttons
that can be used on the menu are displayed at the
bottom line of the screen. You can perform menu
operation using displayed buttons.
Menu
Usable buttons Usable buttons
Display of the usable menu operation buttons
Operating procedures
To display the menu, follow this procedure.
1 Press the MENU/EXIT (@) bution.
{1] MENU | appears.
To select items other than ones not displayed
on MENU 1
Select [2] MENU 2 or [3] MENU 3.
For details of how to select, see the “To change the
item selection menus” described later.
2 Move the cursor to the desired item by pressing
the § or # (@, ©) button.
3 Press the ENTER (@) button.
The adjustment and setting menu selected in step
2 appears.
For detailed information of menus, see “Functions of On-
Screen Menus”.
1) (3) MENU 3 ie provided with PUM. 14N2A/1 4NIE/IANIL20N24/2ONIEVIONIU only.
Using On-Screen Menus
To change the item selection menus
Select NEXT PAGE on the menu to display next item
selection menu and PREVIOUS PAGE on the menu to
display the previous item selection menu.
MENU 3”
= : When selecting NEXT PAGE
@-- : When selecting PREVIOUS PAGE
a) MENU 3is provided with PVM-14N2A/14N2E/1 4N2U/20N2A/
20N2E/20N2U only.
Item selection menus
({]MENU 1
MENU | menu has the following selection items.
VOLUME To obtain the desired volume
CONTRAST To adjust the contrast
BRIGHTNESS To adjust the brightness
To adjust the color intensity
CHROMA
To adjust the phase
How to change the item selection menu
To return to the item selection menu from the
adjustment and setting menus
Press the MENU/EXIT (@) button on the currently
displayed adjustment and setting menu.
To close the menu (to return to the regular
screen)
Press the MENU/EXIT (@) button when the item
selection menu is displayed. The on-screen menu
disappears and the regular screen appears.
[2|MENU 2
MENU 2 menu has the following selection items.
COLOR To select the color system of the
SELECT input signal
DISPLAY To select period of display
To select the menu language
USER MEMORY | To store and recail the values and
settings adjusted by a user, and
recall the factory-settings
LANGUAGE
[3]MENU 3
(for PVM-14N2A/14N2E/1 4N2U/20N2A/
20N2E/20N2U only)
MENU 3 menu has the following selection items.
RGB SYNC To select the sync signal when the
RGB signals are input
ASPECT RATIO To select the aspect ratio
Adjustment and setting menu
VOLUME menu (Factory setting: 50)
‘VOLUME i
Ser am
Adjust the speaker volume.
The volume increases by pressing the # button.
The volume decreases by pressing $ button.
