1-6
VPL-CX20/CS20
1-3-2. C Board
CN106
CN102
CN1101
CN1102
CN105
CN1000
CN800
CN900
CN101
CN103
CN112
CN100
CN115
CN114
CN113
CN110
1
Four screws
(+PSW 2.6 x 5)
3
Remove the C board in the
direction of the arrow.
2
Two
hexagon
screws
C board
