VPL-CX20/CS20
1-5
1
Loosen three screws
4
Sever screws
(Shaft 45)
5
Three screws
(+P M2.6 x 8)
2
Lamp door
3
Filter cover
0 Filter (NR)
!- NR board
8
L board
7
Top panel
6
Lens cover
9
Nylon rivet
Cushion
CN104
CN2300
CN2100
1-3-1. Top Panel
