Specifications
Other
B Other
Specifications
Optical characteristics
Projection system
3 LCD panels, 1 lens, projection
system
LCD panel VPL-CS5: Superhigh-aperture
0.7-inch SVGA panel,
1,440,000 pixels (480,000
pixels × 3)
VPL-CX5: Superhigh-aperture
0.7-inch XGA panel with
micro-lens array, about
2,360,000 pixels (786,432
pixels × 3)
Lens 1.2 times zoom lens (manual)
f 28.2 to 33.8 mm/F 1.8 to 2.15
Lamp 165 W UHP
Projection picture size
Range: 40 to 150 inches (diagonal
measure)
Light output VPL-CS5: ANSI lumen
1)
1800 lm
VPL-CX5: ANSI lumen
1)
2000 lm
(When the Lamp Mode is set to
“High”)
Throwing distance
When the XGA signal is input
40-inch: 1.5 to 1.9 m
(4.9 to 6.2 feet)
60-inch: 2.3 to 2.9 m
(7.5 to 9.5 feet)
80-inch: 3.1 to 3.8 m
(10.2 to 12.5 feet)
100-inch: 3.9 to 4.8 m
(12.8 to 15.7 feet)
120-inch: 4.7 to 5.7 m
(15.4 to 18.7 feet)
150-inch: 5.9 to 7.2 m
(19.4 to 23.6 feet)
There may be a slight difference between the
actual value and the design value shown above.
1) ANSI lumen is a measuring method of
American National Standard IT 7.228.
Electrical characteristics
Color system NTSC3.58/PAL/SECAM/
NTSC
4.43/PAL-M/PAL-N
system, switched automatically/
manually
Resolution VPL-CS5: 600 horizontal TV lines
(Video input)
800 × 600 dots (RGB input)
VPL-CX5: 750 horizontal TV
lines (Video input)
1,024 × 768 dots (RGB input)
Acceptable computer signals
VPL-CS5: fH: 19 to 72 kHz
fV: 48 to 92 Hz
VPL-CX5: fH: 19 to 92 kHz
fV: 48 to 92 Hz
(Maximum input signal resolution:
XGA 1024 × 768
fV: 85 Hz (VPL-CS5),
SXGA+ 1400 × 1050
fV: 60 Hz (VPL-CX5))
1) Set the resolution and the frequency of the
signal of the connected computer within the
range of acceptable preset signals of the
projector.
Applicable video signals
15 kHz RGB/component 50/60
Hz, composite video, S video
Speaker Monaural speaker system, 40 × 20
mm (1
5
/8 ×
13
/16 inches), max.
1 W
Input/Output
Video input VIDEO: phono type
Composite video: 1 Vp-p ±2 dB
sync negative (75 ohms
terminated)
S VIDEO: Y/C mini DIN 4-pin
type (male)
Y (luminance): 1 Vp-p ±2 dB
sync negative (75 ohms
terminated)
C (chrominance): burst
0.286 Vp-p ±2 dB (NTSC)
(75 ohms terminated),
burst 0.3 Vp-p ±2 dB (PAL)
(75 ohms terminated)
INPUT A HD D-sub15-pin (female)
Analog RGB/component:
R/R-Y: 0.7 Vp-p ±2 dB
(75 ohms terminated)
G: 0.7 Vp-p ±2 dB
(75 ohms terminated)
G with sync/Y: 1 Vp-p ±2 dB
sync negative
(75 ohms terminated)
B/B-Y: 0.7 Vp-p ±2 dB
(75 ohms terminated)
SYNC/HD:
Composite sync input: 1-5 Vp-p
high impedance, positive/
negative
Horizontal sync input: 1-5 Vp-p
high impedance, positive/
negative
