Location and Function of Controls
Zoom lever (page 15)
Focus lever (page 15)
Lens shift dial (page 15)
Lens Adjustment Cover (page 15)
Slide open to adjust lens shift.
Projection lens
Remote control Receiver
Ventilation holes (exhaust)
Do not place anything near the ventilation holes as this
may cause internal heat buildup. Do not place your hand
or deformable items (plastic, etc.) near the ventilation
holes or around the projector, as it may cause damage
or personal injury.
ON/STANDBY indicator (page 44)
WARNING indicator (page 44)
Front feet (adjustable) (page 16)
Side cover/Ventilation holes (intake) (page 49)
Security lock
Connects to an optional security cable manufactured by
Kensington.
For details, visit Kensington’s web site.
http://www.kensington.com/
Ventilation holes (intake) (page 49)
Security bar
Connects to a commercially available security chain or
wire.
Control panel (page 6)
Speaker
Terminals (page 5)
Overview
Main Unit
