Specifications
R/R-Y,G/Y,B/B-Y: Gain
Unity,75ohms
SYNC/HD,VD: 4Vp-p (open),
1Vp-p (75ohms)
* DIGITAL RGB signal is not
output from MONITOR OUT
terminal.
AUDIO OUT (variable out):
Stereo minijack
max. 1 Vrms, When an input
signal is 500 mVrms, impedance
less than 5 kilohms
REMOTE RS-232C: D-sub 9-pin (female)
CONTROL S IN/PLUG IN POWER
Stereo minijack 5Vp-p, plug in
power, DC5V
Safety regulations: UL1950, cUL1950, DHHS
(Laser), DNHW (Laser), FCC
Class A, IC Class A,
EN60 950 (NEMKO), CE, C-
Tick, EN60 825-1 (Laser), VCCI
class B, JEIDA
Laser beam
Laser type Class 2
Wavelength 645 nm
Output 1 mW
General
Dimensions 339 × 142 × 335 mm (13
3
/8 × 5
5
/8
× 13
1
/4 inches) (w/h/d)
Mass Approx. 7.2 kg (15 lb 14 oz)
Power requirements
AC 100 to 240 V, 50/60 Hz
Power consumption
Max. 290 W (Standby mode:
5 W)
Heat dissipation 989.6 BTU
Operating temperature
0°C to 40°C (32°F to 104°F)
Operating humidity
35% to 85% (no condensation)
Storage temperature
–20°C to 60°C (–4°F to 140°F)
Storage humidity 10% to 90%
Supplied accessories
Remote Commander RM-PJM610
(1)
Size AA (R6) batteries (2)
HD D-sub 15-pin Cable (1)
(1-791-992-11 or 1-791-992-21)
G: 0.7 Vp-p ±2 dB (75 ohms
terminated)
G with sync/Y: 1 Vp-p ±2 dB
sync negative (75 ohms
terminated)
B/B-Y: 0.7 Vp-p ±2 dB (75
ohms terminated)
SYNC/HD:
Composite sync input: 1-5 Vp-p
high impedance, positive/
negative
Horizontal sync input: 1-5 Vp-p
high impedance, positive/
negative
VD:
Vertical sync input: 1-5 Vp-p
high impedance, positive/
negative
DIGITAL RGB: DFP 20-pin
(TMDS)
USB HUB: Up (B type: female)
× 1, Down (A type: female) × 1
MOUSE (output): 13-pin (female)
(For details, see “Pin assignment” on
page 38 (GB).)
AUDIO: Stereo minijack
500 mVrms, impedance more
than 47 kilohms
INPUT B Analog RGB: HD D-sub15-pin
(female)
R: 0.7 Vp-p ±2 dB (75 ohms
terminated)
G: 0.7 Vp-p ±2 dB (75 ohms
terminated)
G with sync: 1 Vp-p ±2 dB sync
negative (75 ohms terminated)
B: 0.7 Vp-p ±2 dB (75 ohms
terminated)
SYNC/HD:
Composite sync input: 1-5 Vp-p
high impedance, positive/
negative
Horizontal sync input: 1-5 Vp-p
high impedance, positive/
negative
VD:
Vertical sync input: 1-5 Vp-p
high impedance, positive/
negative
MOUSE (output): 13-pin (female)
(For details, see “Pin assignment” on
page 38 (GB).)
AUDIO: Stereo minijack
500 mVrms, impedance more
than 47 kilohms
OUTPUT MONITOR OUT: HD D-sub
15-pin (female)
