Sony VPL-VW50 - Installation Options: PSS-610 Measurements; PSS-610 Suspension Support Measurements

72
When using the 16:9 aspect ratio screen
Unit: mm (inches)
To calculate the installation measurements (SS: Screen Size)
a (minimum) = 31.5 (1
1
/
4
) × SS + 101.6 (4)
a (maximum) = 53.8 (2
1
/
8
) × SS + 102.9 (4
1
/
8
)
x (minimum) = 6.2263 (
1
/
4
) × SS
x (maximum) = 8.0876 (
11
/
32
) × SS + 93.5 (3
3
/
4
) + b
When using the 4:3 aspect ratio screen
Unit: mm (inches)
When Using the PSS-610 Projector Suspension Support
Screen Size
(inches)
40 60 80 100 120 150 180 200 250 300
aMinimum
Distance
1362
(53
5
/
8
)
1992
(78
1
/
2
)
2622
(103
1
/
4
)
3252
(128
1
/
8
)
3882
(152
7
/
8
)
4827
(190
1
/
8
)
5772
(227
1
/
4
)
6402
(252
1
/
8
)
7977
(314
1
/
8
)
9552
(376
1
/
8
)
Maximum
Distance
2255
(87
5
/
8
)
3331
(131
1
/
4
)
4407
(173
5
/
8
)
5483
(215
7
/
8
)
6559
(258
1
/
4
)
8173
(321
7
/
8
)
9787
(385
3
/
8
)
10863
(427
3
/
4
)
13553
(533
5
/
8
)
16243
(639
1
/
2
)
xMinimum
Distance
249
(9
7
/
8
)
374
(14
3
/
4
)
498
(19
5
/
8
)
623
(24
5
/
8
)
747
(29
1
/
2
)
934
(36
7
/
8
)
1121
(44
1
/
4
)
1245
(49
1
/
8
)
1557
(61
3
/
8
)
1868
(73
5
/
8
)
Maximum
Distance
b+417
(b+16
1
/
2
)
b+579
(b+22
7
/
8
)
b+741
(b+29
1
/
4
)
b+902
(b+35
5
/
8
)
b+1064
(b+42)
b+1307
(b+51
1
/
2
)
b+1549
(b+61)
b+1711
(b+67
3
/
8
)
b+2115
(b+83
3
/
8
)
b+2520
(b+99
1
/
4
)
b 150, 175, 200, 250, 275, 300 mm (6, 7, 7
7
/
8
, 9
7
/
8
, 10
7
/
8
, 11
7
/
8
inches) adjustable when using PSS-610
Screen Size
(inches)
40 60 80 100 120 150 180 200 250 300
aMinimum
Distance
1644
(64
3
/
4
)
2415
(95
1
/
8
)
3186
(125
1
/
2
)
3957
(155
7
/
8
)
4728
(186
1
/
4
)
5884
(231
3
/
4
)
7041
(277
1
/
4
)
7812
(307
5
/
8
)
9739
(383
1
/
2
)
11667
(459
3
/
8
)
Maximum
Distance
2737
(107
7
/
8
)
4053
(159
5
/
8
)
5370
(211
1
/
2
)
6687
(263
3
/
8
)
8004
(315
1
/
8
)
9979
(392
7
/
8
)
11955
(470
3
/
4
)
13271
(522
1
/
2
)
16564
(652
1
/
4
)
19856
(781
3
/
4
)
a: Distance between the screen and the installation hole of the upper
ceiling mount bracket (front side)
b: Distance from the ceiling to the bottom surface of the unit
x: Distance between the ceiling and the center of the screen such
that the picture will not be truncated or blocked
PSS-610 Projector Suspension
Support (not supplied)
Ceiling
Center of the screen
Center of the lens
