Sony VPL-VW95ES User Manual

28
The projector incorporates a 3D Sync Transmitter. Depending on the installation
environment of the projector, the 3D glasses may not received 3D signals properly from
the projector’s built-in 3D Sync Transmitter. In this case, connect an optional TMR-PJ1
3D Sync Transmitter and place it near your viewing position.
Tip
Place the optional TMR-PJ1 3D Sync Transmitter directly facing the 3D glasses. Also, in order to
stabilize operation of the 3D glasses, it is recommended that you place the 3D Sync Transmitter near
your viewing position.
CAUTION
Be sure to use straight-type LAN cable of up to 15 m labeled TYPE CM, and do not use
an extension cord.
• The 3D SYNC connector is dedicated for the optional 3D Sync Transmitter. Do not connect
computers or other network devices, to avoid malfunction.
• Be sure to use straight-type LAN cable (not supplied) labeled Cat-7 (Category 7). If you use other
than the specified cable, the 3D Sync Transmitter may occasionally not work.
• Be sure to use cable of up to 15 m, and do not use an extension cord. Also, keep the LAN cable
away from any AC power cords as much as possible.
• Up to one TMR-PJ1 can be connected to a projector. Never connect multiple TMR-PJ1 units,
which may cause a malfunction.
• When connected to the TMR-PJ1, the built-in 3D Sync Transmitter feature of the projector will
automatically turn off. You cannot use both at the same time.
Connecting to an Optional TMR-PJ1 3D Sync Transmitter
Notes
Right side of the projector
TMR-PJ1 3D Sync Transmitter
(not supplied)
LAN cable (not supplied)
: 3D sync signal flow
2 m
(6.6 ft)

Sony VPL-VW95ES Specifications

General

Lamp type	UHP
Native resolution	1920 x 1080 pixels
Native aspect ratio	16:9
Projection technology	SXRD
Screen size compatibility	40 - 300 \
Projector native resolution	1080p (1920x1080)
Vertical synchronization (max)	92 kHz
Vertical synchronization (min)	48 kHz
Horizontal synchronization (max)	72 kHz
Horizontal synchronization (min)	19 kHz
Bulb power	200 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Power consumption (typical)	300 W
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	35 - 85 %
Product color	Black
Interface	2 x HDMI
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC) support	Yes
Light source type	Lamp
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	8 W
Product type	Large venue projector
Focal length range	18.5 - 29.6 mm
Aperture range (F-F)	2.5 - 3.4
Display diagonal	0.61 \
Ethernet LAN	No
Noise level	- dB

Weight and Dimensions

Depth	179.2 mm
Width	470 mm
Height	484.9 mm
Weight	1100 g
Dimensions (WxDxH)	470 x 179.2 x 484.9 mm
