Sony Walkman WM-EX170 Service Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 23 —
C323 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C324 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(EX170)
C324 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(EX172)
C331 1-164-346-11 CERAMIC CHIP 1uF 16V
(EX172)
C332 1-164-005-11 CERAMIC CHIP 0.47uF 25V
(EX172)
C333 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(EX172)
C334 1-126-157-11 ELECT 10uF 20% 16V
(EX172)
C601 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C602 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C603 1-126-176-11 ELECT 220uF 20% 10V
C605 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C606 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C607 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C608 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C609 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C610 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
< CONNECTOR >
L CN301 1-750-346-21 CONNECTOR, FFC/EPC (ZIF) 6P
L CN302 1-750-346-21 CONNECTOR, FFC/EPC (ZIF) 6P (EX170)
* CN302 1-784-527-11 CONNECTOR, FPC (ZIF) 9P (EX172)
< DIODE >
D150 8-719-067-62 DIODE LNJ210C6AOSO
< IC >
IC301 8-759-285-29 IC LA4582CM (EX170)
IC301 8-759-332-69 IC LA4585M-TLM (EX172)
IC331 8-759-488-80 IC NJM2185AV-TE2 (EX172)
IC601 8-759-447-73 IC LB1979V-TLM
< JACK >
J301 1-750-061-11 JACK,DC(POLARITY UNIFIED TYPE)(DC IN 3V)
(E,6E,9E)
J302 1-565-287-11 JACK(PHONES)
< JUMPER RESISTOR >
JR10 1-216-295-91 SHORT 0 (EXCEPT E,6E,9E)
JR201 1-216-295-91 SHORT 0
JR202 1-216-295-91 SHORT 0 (EX172)
JR301 1-216-296-91 SHORT 0
JR302 1-216-296-91 SHORT 0
JR303 1-216-296-91 SHORT 0
JR304 1-216-296-91 SHORT 0
JR305 1-216-296-91 SHORT 0
JR306 1-216-296-91 SHORT 0
JR307 1-216-296-91 SHORT 0 (EX172)
JR308 1-216-296-91 SHORT 0
JR309 1-216-296-91 SHORT 0
JR310 1-216-296-91 SHORT 0
JR311 1-216-296-91 SHORT 0
JR312 1-216-296-91 SHORT 0 (EX170)
JR313 1-216-296-91 SHORT 0
JR314 1-216-296-91 SHORT 0
JR315 1-216-296-91 SHORT 0
JR316 1-216-296-91 SHORT 0 (EX172)
JR317 1-216-296-91 SHORT 0 (EX172)
JR318 1-216-296-91 SHORT 0 (EX172)
JR319 1-216-296-91 SHORT 0 (EX172)
JR320 1-216-296-91 SHORT 0 (EX172)
JR321 1-216-296-91 SHORT 0 (EX172)
JR322 1-216-296-91 SHORT 0 (EX172)
JR323 1-216-296-91 SHORT 0 (EX172)
JR324 1-216-296-91 SHORT 0 (EX172)
< RESISTOR >
R101 1-216-089-91 RES,CHIP 47K 5% 1/10W
R103 1-216-079-00 METAL CHIP 18K 5% 1/10W
R104 1-216-075-00 METAL CHIP 12K 5% 1/10W
R105 1-216-117-00 METAL CHIP 680K 5% 1/10W
R106 1-216-043-91 RES,CHIP 560 5% 1/10W
(EX170)
R106 1-216-046-00 METAL CHIP 750 5% 1/10W
(EX172)
R107 1-216-003-11 RES,CHIP 12 5% 1/10W
(EX170:E,9E)
R107 1-216-295-91 SHORT 0 (CND,AEP,EE)
R107 1-216-311-00 METAL CHIP 6.8 5% 1/10W
(EX172:E,6E,9E)
R107 1-216-001-00 RES,CHIP 10 5% 1/10W
(FR)
R109 1-216-095-00 METAL CHIP 82K 5% 1/10W
(E,6E,9E)
R109 1-216-107-00 METAL CHIP 270K 5% 1/10W
(CND,AEP,EE,FR)
R110 1-216-049-91 RES,CHIP 1K 5% 1/10W
R111 1-216-174-00 RES,CHIP 100 5% 1/8W
R150 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R201 1-216-089-91 RES,CHIP 47K 5% 1/10W
R203 1-216-079-00 METAL CHIP 18K 5% 1/10W
R204 1-216-075-00 METAL CHIP 12K 5% 1/10W
R205 1-216-117-00 METAL CHIP 680K 5% 1/10W
R206 1-216-043-91 RES,CHIP 560 5% 1/10W
(EX170)
R206 1-216-046-00 METAL CHIP 750 5% 1/10W
(EX172)
R207 1-216-003-11 RES,CHIP 12 5% 1/10W
(EX170:E,9E)
R207 1-216-295-91 SHORT 0 (CND,AEP,EE)
R207 1-216-311-00 METAL CHIP 6.8 5% 1/10W
(EX172:E,6E,9E)
R207 1-216-001-00 RES,CHIP 10 5% 1/10W
(FR)
R209 1-216-095-00 METAL CHIP 82K 5% 1/10W
(E,6E,9E)
R209 1-216-107-00 METAL CHIP 270K 5% 1/10W
(CND,AEP,EE,FR)
R210 1-216-049-91 RES,CHIP 1K 5% 1/10W
R211 1-216-025-91 RES,CHIP 100 5% 1/10W
R301 1-216-049-91 RES,CHIP 1K 5% 1/10W
R305 1-216-081-00 METAL CHIP 22K 5% 1/10W
MAIN
