Sony Walkman WM-EX170 Service Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 24 —
R306 1-216-077-00 METAL CHIP 15K 5% 1/10W
(EX170)
R306 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(EX172)
R309 1-216-113-00 METAL CHIP 470K 5% 1/10W
R324 1-216-025-91 RES,CHIP 100 5% 1/10W
(EX170)
R324 1-216-298-00 METAL CHIP 2.2 5% 1/10W
(EX172)
R331 1-216-001-00 METAL CHIP 10 5% 1/10W
(EX172)
R332 1-216-081-00 METAL CHIP 22K 5% 1/10W
(EX172)
R333 1-216-688-11 METAL CHIP 36K 0.5% 1/10W
(EX172)
R601 1-216-121-91 RES,CHIP 1M 5% 1/10W
R602 1-216-121-91 RES,CHIP 1M 5% 1/10W
R603 1-216-121-91 RES,CHIP 1M 5% 1/10W
R604 1-216-073-00 METAL CHIP 10K 5% 1/10W
R605 1-216-049-91 RES,CHIP 1K 5% 1/10W
R606 1-216-097-91 RES,CHIP 100K 5% 1/10W
R607 1-216-073-00 METAL CHIP 10K 5% 1/10W
R608 1-216-049-91 RES,CHIP 1K 5% 1/10W
< VARIABLE RESISTOR >
RV301 1-225-544-11 RES, VAR, CARBON 10K/10K(VOLUME)
RV601 1-238-663-11 RES, ADJ, CARBON 4.7K
< SWITCH >
S302 1-762-917-11 SWITCH, DETECTION (SMALL TYPE)(POWER)
S303 1-692-298-11 SWITCH, SLIDE(TAPE SELECTOR)
S305 1-692-298-11 SWITCH, SLIDE(AVLS)
< THERMISTOR >
TH601 1-810-794-11 THERMISTOR, POSITIVE
************************************************************
MISCELLANEOUS
*************
11 1-475-439-11 MEGA BASS UNIT (SWITCH) (EX170)
11 1-475-441-11 MEGA BASS UNIT (DOLBY) (EX172)
HP901 1-500-517-11 HEAD, MAGNETIC (PLAYBACK)
M901 1-763-073-11 MOTOR
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-505-521-11 HEADPHONES (MDR-023)(EXCEPT E,6E,9E)
3-022-755-01 CLIP, BELT
3-861-488-11 MANUAL, INSTRUCTION(ENGLISH/FRENCH)
(CND,EE)
3-861-488-21 MANUAL, INSTRUCTION
(ENGLISH/GERMAN/SPANISH/DUTCH/FRENCH
/ITALIAN/PORTUGUESE/FINNISH)(AEP)
3-861-488-31 MANUAL, INSTRUCTION(FRENCH)(AEP,FR)
3-861-488-41 MANUAL, INSTRUCTION
(GERMAN/POLISH/RUSSIAN/HUNGARIAN
/BULGARIAN/CZECH/GREEK/TURKISH)(EE)
3-861-488-51 MANUAL, INSTRUCTION
(ENGLISH/CHINESE/KOREAN)(E)
3-861-488-61 MANUAL, INSTRUCTION
(SPANISH/PORTUGUESE)(6E)
3-861-488-71 MANUAL, INSTRUCTION
(ENGLISH/CHINESE/KOREAN)(9E)
8-953-224-90 HEADPHONE MDR-E802LP//K SET(E,6E,9E)
MAIN
WM-EX170/EX172
Sony Corporation
Personal A&V Products Company
98B1683-1
Printed in Japan © 1998.2
Published by Quality Engineering Dept.
(Shibaura)
9-923-335-11
