Sony Walkman WM-FX488 Service Manual

20
WM-FX488
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
C704 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C705 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C706 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C707 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C708 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C709 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C710 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C711 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C712 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C713 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C714 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C715 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C716 1-162-966-11 CERAMIC CHIP 2200PF 10% 50V
C721 1-126-518-11 ELECT 470uF 20% 4V
C722 1-126-518-11 ELECT 470uF 20% 4V
C732 1-115-156-11 CERAMIC CHIP 1uF 10V
< FILTER >
CF1 1-577-574-11 FILTER, CERAMIC
CF3 1-767-480-11 FILTER, CERAMIC (AM)
< TRIMMER >
CT1 1-141-422-11 CAP, ADJ 10PF (AM TRACKING)
< DIODE >
D1 8-759-072-60 DIODE Z84C4306FEC
D2 8-719-080-77 DIODE MA2S357(E)-(TX).SO
D3 8-719-080-77 DIODE MA2S357(E)-(TX).SO
D5 6-500-174-01 DIODE MA2SP0100LSO (6E)
D401 8-719-158-49 DIODE RD12SB2
D402 8-719-404-50 DIODE MA111-TX
D701 8-719-049-09 DIODE 1SS367-T3SONY
< FERRITE BEAD >
FB1 1-414-760-21 FERRITE 0uH
FB101 1-500-329-21 FERRITE 0uH
FB201 1-500-329-21 FERRITE 0uH
FB301 1-500-329-21 FERRITE 0uH
< IC >
IC1 6-701-310-01 IC TA2154FN(EL)
IC301 6-701-831-01 IC TA2160FN(EL)
IC601 8-759-356-46 IC MM1279XVBE
IC701 6-802-602-01 IC TC9329FA-CFX1738
IC703 8-759-430-08 IC PST9008NL
< JACK >
J301 1-565-287-11 JACK (i)
<JUMPER RESISTOR>
JC2 1-216-864-11 METAL CHIP 0 5% 1/10W
(E, CH)
JC6 1-216-864-11 METAL CHIP 0 5% 1/10W
JC701 1-216-864-11 METAL CHIP 0 5% 1/10W
(6E)
JC702 1-216-864-11 METAL CHIP 0 5% 1/10W
(E, CH)
JC703 1-216-864-11 METAL CHIP 0 5% 1/10W
(E, CH)
JC704 1-216-864-11 METAL CHIP 0 5% 1/10W
(6E)
< COIL >
L1 1-412-967-31 INDUCTOR 0.1uH
L2 1-419-594-11 COIL, RF (FM) (FM TRACKING)
L3 1-419-135-21 INDUCTOR 27nH
L4 1-754-265-11 ANTENNA, FERRITE-ROD (AM TRACKING)
L5 1-428-859-11 COIL (AM OSC) (AM FREQUENCY COVERAGE)
L401 1-412-010-41 INDUCTOR 22uH
L701 1-412-995-21 INDUCTOR 22uH
< TRANSISTOR >
Q101 8-729-230-72 TRANSISTOR 2SA1362YG
Q102 8-729-230-72 TRANSISTOR 2SA1362YG
Q201 8-729-230-72 TRANSISTOR 2SA1362YG
Q202 8-729-230-72 TRANSISTOR 2SA1362YG
Q301 8-729-230-49 TRANSISTOR 2SC2712-YG
Q302 8-729-230-72 TRANSISTOR 2SA1362YG
Q303 8-729-429-44 TRANSISTOR XP1501
Q305 8-729-425-94 TRANSISTOR XP1116-TXE
Q401 8-729-602-21 TRANSISTOR 2SC4154-F
Q402 8-729-800-71 TRANSISTOR 2SB815B7-TB
Q701 8-729-602-21 TRANSISTOR 2SC4154-F
Q702 8-729-602-21 TRANSISTOR 2SC4154-F
Q703 8-729-800-71 TRANSISTOR 2SB815B7-TB
Q704 8-729-800-71 TRANSISTOR 2SB815B7-TB
Q705 8-729-800-71 TRANSISTOR 2SB815B7-TB
Q707 8-729-800-71 TRANSISTOR 2SB815B7-TB
< RESISTOR >
R1 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5 1-216-845-11 METAL CHIP 100K 5% 1/10W
R6 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8 1-216-853-11 METAL CHIP 470K 5% 1/10W
R9 1-216-853-11 METAL CHIP 470K 5% 1/10W
R11 1-216-821-11 METAL CHIP 1K 5% 1/10W
(6E)
R12 1-216-821-11 METAL CHIP 1K 5% 1/10W
(6E)
R16 1-216-864-11 METAL CHIP 0 5% 1/10W
(E, CH)
R17 1-216-833-11 METAL CHIP 10K 5% 1/10W
R18 1-216-864-11 METAL CHIP 0 5% 1/10W
R20 1-216-837-11 METAL CHIP 22K 5% 1/10W
R21 1-216-837-11 METAL CHIP 22K 5% 1/10W
R40 1-216-864-11 METAL CHIP 0 5% 1/10W
R101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R103 1-216-853-11 METAL CHIP 470K 5% 1/10W
R104 1-216-817-11 METAL CHIP 470 5% 1/10W
R105 1-216-809-11 METAL CHIP 100 5% 1/10W
R106 1-216-849-11 METAL CHIP 220K 5% 1/10W
R107 1-216-837-11 METAL CHIP 22K 5% 1/10W
R108 1-216-833-11 METAL CHIP 10K 5% 1/10W
R109 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R110 1-216-821-11 METAL CHIP 1K 5% 1/10W
R111 1-216-849-11 METAL CHIP 220K 5% 1/10W
R112 1-216-809-11 METAL CHIP 100 5% 1/10W
(E, CH)
R112 1-216-864-11 METAL CHIP 0 5% 1/10W
(6E)
Ver 1.1 2003.01

Sony Walkman WM-FX488 Specifications

Power

power requirements	DC 1.5V, AA Battery x 1
battery life (play)	35 Hours w/Sony Alkaline Battery
battery life (tuner)	40 Hours w/Alkaline Battery

Frequency Range

FM frequency range	87.5-108MHz
AM frequency range	530-1710kHz
TV frequency range	Channels 2-13
Weather Band frequency range	Channels 1-7

Weight and Dimensions

weight	158 g
width	83.6 mm
height	112 mm
depth	28.3 mm
