Sony Walkman WM-FX488 Service Manual

19
WM-FX488
SECTION 6
ELECTRICAL PARTS LIST
MAIN
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
When indicating parts by reference num-
ber, please include the board.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
• Abbreviation
CH : Chinese
E: No indication of country of origin
6E : Indication of country of origin
* A-3178-912-A MAIN BOARD ASSY (E, CH)
* A-3178-926-A MAIN BOARD ASSY (6E)
**************
< CAPACITOR >
C1 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2 1-124-259-11 ELECT 4.7uF 20% 16V
C3 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C6 1-126-153-11 ELECT 22uF 20% 6.3V
C7 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C8 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C9 1-124-434-00 ELECT 220uF 20% 4V
C10 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C11 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(E, CH)
C11 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V(6E)
C12 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(E, CH)
C12 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V(6E)
C13 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(E, CH)
C13 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V(6E)
C14 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(E, CH)
C14 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V(6E)
C15 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C16 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C17 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C18 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C20 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C21 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C22 1-162-911-11 CERAMIC CHIP 6PF 0.25PF 50V
C23 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C24 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C26 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C28 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C29 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C30 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C31 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C36 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C41 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C44 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C46 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V(6E)
C56 1-162-911-11 CERAMIC CHIP 6PF 0.25PF 50V
C101 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C103 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C104 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C106 1-115-156-11 CERAMIC CHIP 1uF 10V
C107 1-115-156-11 CERAMIC CHIP 1uF 10V
C108 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C109 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C110 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C201 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C203 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C204 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C206 1-115-156-11 CERAMIC CHIP 1uF 10V
C207 1-115-156-11 CERAMIC CHIP 1uF 10V
C208 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C209 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C210 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C301 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C304 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C305 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C306 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C307 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C308 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C309 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C310 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C311 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C312 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C316 1-115-156-11 CERAMIC CHIP 1uF 10V
C322 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C324 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C325 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C330 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C331 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C402 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C403 1-164-505-91 CERAMIC CHIP 2.2uF 16V
C404 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C405 1-126-153-11 ELECT 22uF 20% 6.3V
C406 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C407 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C408 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C409 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C503 1-124-434-00 ELECT 220uF 20% 4V
C601 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C602 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C603 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C604 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C605 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C606 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C607 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C608 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C610 1-115-156-11 CERAMIC CHIP 1uF 10V
C700 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C701 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C702 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C703 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
Ver 1.1 2003.01

Sony Walkman WM-FX488 Specifications

Power

power requirements	DC 1.5V, AA Battery x 1
battery life (play)	35 Hours w/Sony Alkaline Battery
battery life (tuner)	40 Hours w/Alkaline Battery

Frequency Range

FM frequency range	87.5-108MHz
AM frequency range	530-1710kHz
TV frequency range	Channels 2-13
Weather Band frequency range	Channels 1-7

Weight and Dimensions

weight	158 g
width	83.6 mm
height	112 mm
depth	28.3 mm
