8
WM-FX488
Adjustment Location :
[MAIN BOARD] (SIDE A)
IC1
TP30
TP12
(VT)
L5 : AM Frequency Coverage Adjustment
L2 : FM Tracking Adjustment
L4 : AM Tracking Adjustment
CT1 : AM Tracking Adjustment
TP30 : FM Sgnal input
