– 7 –
MEGA BASS UNIT (DOLBY)
4
mega bass unit (dolby)
1
two knobs (rotary)
5
flexible board
2
claw
3
Remove five claws as
move the mega bass
unit (dolby) to direction
of the arrow
A
.
three claws
claw
claw
A
