– 6 –
CASSETTE HOLDER ASS’Y
NOTE FOR INSTALLATION
Note: Follow the assembly procedure in the numerical order given.
• SPRING (TORSION)
A
B
1
flexible board
(CN302)
3
portion
B
to release
the hinge plate.
5
spring (torsion)
4
cassette holder ass’y
2
Insert a precision screwdriver (1.4 mm flat-blade)
vertically in to portion
A
to release the hinge plate.
3
cassette holder ass’y
1
Attach the spring (torsion) as
shown in the figure.
2
Insert the spring (torsion) in the
ditch to direction of the arrow
A
.
A
