– 2 –
HP901
PM901
M901
M901
101
102
103
104
105
106
107
108
109
110
111
113
114
115
116
117
119
120
FORMER TYPE
NEW TYPE
120
134
121
121
122
123
124
125
126
127
128
129
130
131
130
132
133
134
!
: Changed portion
Caution : Since the new motor (M901) and chassis (S) ASSY are not compatible with the former ones, when replacing either of these
parts, replace them with the same version.
Ref. No Part No. Description Remark Part No. Description Remark
Former Type New Type
108 3-386-694-11 WASHER
109 X-3372-852-1 FLYWHEEL (N) ASSY
116 3-007-435-01 GEAR (FR)
120 3-007-427-01 SCREW (IB LOCK)
121 X-3374-094-1 CHASSIS (S) ASSY (Y)
122 3-007-455-01 SPRING (R), TORSION
124 3-007-456-01 SPRING (N), TORSION
134 –––––––––––
HP901 1-500-280-11 HEAD, MAGNETIC (PLAYBACK)
M901 1-698-885-11 MOTOR
PM901 1-454-674-31 SOLENOID, PLUNGER
3-386-694-21 WASHER
X-3372-852-4 FLYWHEEL (N) ASSY
3-016-696-01 GEAR (FRN)
3-335-797-01 SCREW (M1.4 x 2), TOOTHED LOCK
X-3374-420-1 CHASSIS (S) ASSY (M)
3-019-710-01 SPRING (R), TORSION
3-019-709-01 SPRING (N), TORSION
3-335-797-21 SCREW (M1.4 x 3), TOOTHED LOCK
1-500-537-11 HEAD, MAGNETIC (PLAYBACK)
X-3376-217-1 MOTOR ASSY
1-454-674-32 SOLENOID, PLUNGER
%
%
#
@
^
^
^
^
@
$
$
^
#
r
NO INTERCHANGEABILITY OF MOTORS DUE TO CHANGE OF MECHANISM DECK
MECHANISM DECK SECTION (Service Manual See page 22)
(MT-WMEX655-125)
#
