Sony WM-FX171

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 31 —
C305 1-126-176-11 ELECT 220uF 20% 10V
C306 1-115-156-11 CERAMIC CHIP 1uF 10V
C308 1-126-162-11 ELECT 3.3uF 20% 50V
C309 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
(FX171, FX177)
C309 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(FX173)
C310 1-115-156-11 CERAMIC CHIP 1uF 10V
C311 1-113-619-11 CERAMIC CHIP 0.47uF 10V
(FX171, FX177)
C311 1-115-156-11 CERAMIC CHIP 1uF 10V
(FX173)
C312 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(FX173)
C312 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
(FX171, FX177)
C313 1-115-156-11 CERAMIC CHIP 1uF 10V
C314 1-115-156-11 CERAMIC CHIP 1uF 10V
C315 1-126-153-11 ELECT 22uF 20% 6.3V
C317 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C318 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C319 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C322 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C325 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C328 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C329 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C601 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C602 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C603 1-126-176-11 ELECT 220uF 20% 10V
C605 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C606 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C607 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C608 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C609 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C610 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C612 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< FILTER >
CF1 1-527-870-00 FILTER 455kHz
CF2 1-767-733-71 FILTER ASSY, CERAMIC 10.7MHz
< CONNECTOR >
L CN301 1-750-346-21 CONNECTOR, FFC/EPC (ZIF) 6P
L CN302 1-750-346-21 CONNECTOR, FFC/EPC (ZIF) 6P(FX171, FX177)
* CN302 1-784-527-11 HOUSING, CONNECTOR (ZIF-J) 9P (FX173)
< FILTER >
CP1 1-236-711-21 FILTER, BAND PASS (EXCEPT EE)
CP1 1-239-813-21 FILTER, BAND PASS (EE)
< VARIABLE CAPACITOR >
CV1 1-141-592-11 CAP, VAR, POLYETHYLENE (TUNING)
(FX171: EXCEPT EE, FX177)
CV1 1-141-592-21 CAP, VAR, POLYETHYLENE (TUNING)
(FX171: EE)
CV1 1-141-595-11 CAP, VAR, POLYETHYLENE (–M) (TUNING)
(FX173)
< DIODE >
D120 8-719-067-62 DIODE LNJ210C6AOSO (BATT)
< IC >
IC1 8-759-493-20 IC TA2111F-(EL)
IC301 8-759-285-29 IC LA4582CM
IC601 8-759-447-73 IC LB1979V-TLM
< JACK >
J301 1-750-061-11 JACK, DC (POLARITY UNIFIED TYPE) (DC 3V)
(E, C&SA, PA)
J302 1-565-287-11 JACK (PHONES)
< JUMPER RESISTOR >
JR1 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP, IT, FR, EE, E, EA)
JR2 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP, IT, FR, EE, E, EA)
JR3 1-216-821-11 METAL CHIP 1K 5% 1/16W
(AEP, IT, FR, EE, E, EA)
JR4 1-216-864-11 METAL CHIP 0 5% 1/16W
(C&SA, PA, CND)
JR5 1-216-864-11 METAL CHIP 0 5% 1/16W
(C&SA, PA, CND)
< COIL >
L1 1-501-962-11 ANTENNA, FERRITE-ROD
L2 1-416-623-11 COIL (WITH CORE) (RF-T) (EXCEPT IT, EA, EE)
L2 1-416-624-11 COIL (WITH CORE) (RF-T) (IT, EA)
L2 1-416-625-91 COIL (WITH CORE) (RF-T) (EE)
L3 1-416-626-11 COIL (WITH CORE) (OSC-T) (EXCEPT IT,EA,EE)
L3 1-416-627-11 COIL (WITH CORE) (OSC-T) (IT, EA)
L3 1-416-628-11 COIL (WITH CORE) (OSC-T) (EE)
L4 1-406-408-11 COIL (OSC) (EXCEP IT, EA)
L4 1-406-409-11 COIL (OSC) (IT, EA)
L101 1-414-385-11 INDUCTOR CHIP 0uH
L201 1-414-385-11 INDUCTOR CHIP 0uH
L301 1-414-385-11 INDUCTOR CHIP 0uH
L302 1-414-385-11 INDUCTOR CHIP 0uH
< TRANSISTOR >
Q2 8-729-216-22 TRANSISTOR 2SA1162-G
Q101 8-729-207-65 TRANSISTOR RN1410
Q201 8-729-207-65 TRANSISTOR RN1410
Q301 8-729-230-49 TRANSISTOR 2SC2712-YG
Q302 8-729-216-22 TRANSISTOR 2SA1162-G
< RESISTOR >
R1 1-216-864-11 METAL CHIP 0 5% 1/16W
R2 1-216-839-11 METAL CHIP 33K 5% 1/16W
R3 1-216-835-11 METAL CHIP 15K 5% 1/16W
R4 1-216-835-11 METAL CHIP 15K 5% 1/16W
R5 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R6 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R7 1-216-815-11 METAL CHIP 330 5% 1/16W
R8 1-216-797-11 METAL CHIP 10 5% 1/16W
R9 1-216-815-11 METAL CHIP 330 5% 1/16W
R101 1-216-821-11 METAL CHIP 1K 5% 1/16W
MAIN
