Sony WM-FX171

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 32 —
R103 1-216-835-11 METAL CHIP 15K 5% 1/16W
R104 1-216-835-11 METAL CHIP 15K 5% 1/16W
R105 1-216-855-11 METAL CHIP 680K 5% 1/16W
R106 1-216-818-11 METAL CHIP 560 5% 1/16W
R107 1-216-789-11 METAL CHIP 2.2 5% 1/16W
(AEP, IT, EE, FX173: CND)
R107 1-216-797-11 METAL CHIP 10 5% 1/16W
(FR, E, C&SA, EA, PA)
R107 1-216-864-11 METAL CHIP 0 5% 1/16W
(FX177)
R109 1-216-850-11 METAL CHIP 270K 5% 1/16W
(AEP, IT, EE, CND)
R109 1-216-846-11 METAL CHIP 120K 5% 1/16W
(FR, E, C&SA, EA, PA)
R120 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R201 1-216-821-11 METAL CHIP 1K 5% 1/16W
R203 1-216-835-11 METAL CHIP 15K 5% 1/16W
R204 1-216-835-11 METAL CHIP 15K 5% 1/16W
R205 1-216-855-11 METAL CHIP 680K 5% 1/16W
R206 1-216-818-11 METAL CHIP 560 5% 1/16W
R207 1-216-789-11 METAL CHIP 2.2 5% 1/16W
(AEP, IT, EE, FX173: CND)
R207 1-216-797-11 METAL CHIP 10 5% 1/16W
(FR, E, C&SA, EA, PA)
R207 1-216-864-11 METAL CHIP 0 5% 1/16W
(FX177)
R209 1-216-850-11 METAL CHIP 270K 5% 1/16W
(AEP, IT, EE, CND)
R209 1-216-846-11 METAL CHIP 120K 5% 1/16W
(FR, E, C&SA, EA, PA)
R301 1-216-821-11 METAL CHIP 1K 5% 1/16W
R305 1-216-837-11 METAL CHIP 22K 5% 1/16W
(FX171: EXCEPT IT, FX173, FX177)
R305 1-216-835-11 METAL CHIP 15K 5% 1/16W
(FX171: IT)
R306 1-216-835-11 METAL CHIP 15K 5% 1/16W
(FX171, FX177)
R306 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(FX173)
R308 1-216-835-11 METAL CHIP 15K 5% 1/16W
R320 1-216-841-11 METAL CHIP 47K 5% 1/16W
R321 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R322 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R601 1-216-857-11 METAL CHIP 1M 5% 1/16W
R602 1-216-857-11 METAL CHIP 1M 5% 1/16W
R603 1-216-857-11 METAL CHIP 1M 5% 1/16W
R604 1-216-839-11 METAL CHIP 33K 5% 1/16W
R605 1-216-821-11 METAL CHIP 1K 5% 1/16W
R606 1-216-845-11 METAL CHIP 100K 5% 1/16W
R607 1-216-833-11 METAL CHIP 10K 5% 1/16W
R608 1-216-821-11 METAL CHIP 1K 5% 1/16W
R609 1-216-821-11 METAL CHIP 1K 5% 1/16W
< VARIABLE RESISTOR >
RV301 1-225-362-11 RES, VAR, CARBON (VOLUME)
RV601 1-238-663-11 RES, ADJ, CARBON 4.7K
< SWITCH >
S302 1-762-917-11 SWITCH, DETECTION (SMALL TYPE) (POWER)
S303 1-692-298-11 SWITCH, SLIDE (FM MODE/TAPE SELECTOR)
S304 1-692-299-11 SWITCH, SLIDE (FUNCTION)
S305 1-692-298-11 SWITCH, SLIDE (AVLS)
< TRANSFORMER >
T1 1-404-949-11 TRANSFORMER, IF
< THERMISTOR >
TH601 1-810-794-11 THERMISTOR, POSITIVE
< VIBRATOR >
X2 1-767-733-71 FILTER ASSY, CERAMIC 10.7MHz
************************************************************
MISCELLANEOUS
**************
10 1-475-439-11 MEGA BASS UNIT (SWITCH) (FX171, FX177)
10 1-475-440-11 MEGA BASS UNIT (ROTARY) (FX173)
HP901 1-667-291-11 HEAD FLEXIBLE BOARD (W/PLAYBACK HEAD)
M901 1-763-073-11 MOTOR
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-505-521-11 HEADPHONE (MDR-023) (AEP, IT, FR, EE, CND)
1-528-179-11 BATTERY, NICKEL. CADMIUN (FX177)
1-528-441-11 BATTERY CHARGER (BC-810U) (FX177)
3-020-998-01 CLIP, BELT
3-861-489-11 MANUAL, INSTRUCTION (ENGLISH)
3-861-489-21 MANUAL, INSTRUCTION (FRENCH)
3-861-489-31 MANUAL, INSTRUCTION (ENGLISH
/FRENCH/GERMAN/ITALIAN) (FX171, FX173)
3-861-489-41 MANUAL, INSTRUCTION (SPANISH/DUTCH
/SWEDISH/PORTUGUESE) (FX171, FX173)
3-861-489-51 MANUAL, INSTRUCTION (POLISH/CZECK
/GREEK/TURKISH) (FX171, FX173)
3-861-489-61 MANUAL, INSTRUCTION (RUSSIAN
/HUNGARIAN/BULGARIAN) (FX171, FX173)
3-861-489-71 MANUAL, INSTRUCTION (ENGLISH/CHINESE
/KOREAN) (FX171, FX173)
3-861-489-81 MANUAL, INSTRUCTION (ENGLISH/CHINESE
/KOREAN) (FX171, FX173)
8-953-224-90 HEADPHONE MDR-E802LP//K SET
(E, C&SA, EA, PA)
MAIN
WM-FX171/FX173/FX177
Sony Corporation
Personal A&V Products Company
98B1683-1
Printed in Japan © 1998.2
Published by Quality Engineering Dept.
(Shibaura)
9-923-333-11
