– 27 –
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
MAIN
When indicating parts by reference
number, please include the board.
A-3016-995-A MAIN BOARD, COMPLETE (FX267: US)
A-3016-996-A MAIN BOARD, COMPLETE (FX267: AEP)
A-3016-997-A MAIN BOARD, COMPLETE (FX267: 2CE7)
A-3021-026-A MAIN BOARD, COMPLETE (FX269)
A-3021-027-A MAIN BOARD, COMPLETE (FX267: FR)
A-3021-103-A MAIN BOARD, COMPLETE (FX267: E)
*********************
3-007-009-01 TERMINAL (+), BATTERY
3-007-010-01 TERMINAL (–), BATTERY
< CAPACITOR >
C2 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C4 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C5 1-163-093-00 CERAMIC CHIP 10PF 5% 50V
C6 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C7 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C8 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C9 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C10 1-163-097-00 CERAMIC CHIP 15PF 5% 50V
C12 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C13 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C14 1-163-220-11 CERAMIC CHIP 3PF 0.25PF 50V
C16 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C17 1-115-156-11 CERAMIC CHIP 1uF 10V
C18 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C19 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C20 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C21 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C22 1-126-963-11 ELECT 4.7uF 20% 50V
C23 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C24 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C25 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(FX267: AEP, 2CE7, FR)
C25 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
(FX267: US, E/FX269)
C26 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(FX267: AEP, 2CE7, FR)
C26 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
(FX267: US, E/FX269)
C27 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C28 1-126-924-11 ELECT 330uF 20% 6.3V
C29 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(FX267: US, E/FX269)
C30 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(FX267: AEP, 2CE7, FR)
C34 1-163-098-00 CERAMIC CHIP 16PF 5% 50V
(FX267: AEP, 2CE7, FR)
C34 1-163-163-00 CERAMIC CHIP 18PF 5% 50V
(FX267: US, E/FX269)
C35 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C36 1-115-156-11 CERAMIC CHIP 1uF 10V
C40 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C41 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C101 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C102 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C103 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C104 1-126-157-11 ELECT 10uF 20% 16V
C105 1-115-156-11 CERAMIC CHIP 1uF 10V
C107 1-115-156-11 CERAMIC CHIP 1uF 10V
C108 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C109 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C203 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C204 1-126-157-11 ELECT 10uF 20% 16V
C205 1-115-156-11 CERAMIC CHIP 1uF 10V
C207 1-115-156-11 CERAMIC CHIP 1uF 10V
C208 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C209 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C301 1-126-923-11 ELECT 220uF 20% 10V
C302 1-117-579-11 DOUBLE LAYER 0.1F 3.5V
C303 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C304 1-128-551-11 ELECT 22uF 20% 25V
C305 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C306 1-163-100-00 CERAMIC CHIP 20PF 5% 50V
C307 1-128-551-11 ELECT 22uF 20% 25V
C308 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C309 1-115-156-11 CERAMIC CHIP 1uF 10V
C310 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C319 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C320 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C321 1-126-933-11 ELECT 100uF 20% 10V
C322 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C323 1-128-551-11 ELECT 22uF 20% 25V
C324 1-115-156-11 CERAMIC CHIP 1uF 10V
C325 1-128-551-11 ELECT 22uF 20% 25V
• Abbreviation
FR : French
