– 29 –
SECTION 7
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference
number, please include the board.
• Abbreviation
CND : Canadian model.
C&SA : Central and South America model.
CH : Chinese model.
FR : French model.
CEV : Poland, Czech, Greece and Turkey
model.
EE : East European model.
9E : No indication of country of origin.
E : Indication of country of origin.
DISPLAY
A-3061-893-A DISPLAY BOARD, COMPLETE
(FX479:US,CND,C&SA)
A-3061-896-A DISPLAY BOARD, COMPLETE
(FX479:AEP,FR,CEV,CH)
A-3061-899-A DISPLAY BOARD, COMPLETE (FX479:EE)
A-3061-906-A DISPLAY BOARD, COMPLETE
(FX477:US,CND,C&SA)
A-3061-909-A DISPLAY BOARD, COMPLETE
(FX477:AEP,FR,CEV)
A-3061-912-A DISPLAY BOARD, COMPLETE (FX477:EE)
A-3061-913-A DISPLAY BOARD, COMPLETE (FX477:E,9E,CH)
A-3061-920-A DISPLAY BOARD, COMPLETE (FX479:E)
************************
< CAPACITOR >
C701 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C704 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C705 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C706 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C707 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C708 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V
C709 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C710 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C711 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C712 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C713 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C714 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C715 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C716 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C717 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C718 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V
C719 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C720 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C721 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C722 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< IC >
IC701 8-759-574-70 IC TC9327F-113
IC702 8-759-469-63 IC S-81215SGUP-DQK-T1
< COIL >
L701 1-412-995-21 INDUCTOR 22uH
L702 1-412-972-31 INDUCTOR 0.27uH (EXCEPT EE)
L702 1-412-973-11 INDUCTOR 0.33uH (EE)
< LIQUID CRYSTAL DISPLAY >
ND701 1-803-304-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q701 8-729-602-21 TRANSISTOR 2SC4154-F
Q702 8-729-231-96 FET 2SK880GR-TE85L
Q703 8-729-423-55 TRANSISTOR 2SC3931-D
< RESISTOR >
R700 1-216-817-11 METAL CHIP 470 5% 1/16W
R701 1-216-835-11 METAL CHIP 15K 5% 1/16W
R702 1-216-841-11 METAL CHIP 47K 5% 1/16W
R703 1-216-805-11 METAL CHIP 47 5% 1/16W
R704 1-216-835-11 METAL CHIP 15K 5% 1/16W
R705 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R706 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R707 1-218-899-11 RES,CHIP 150K 0.50% 1/16W
R708 1-218-895-11 RES,CHIP 100K 0.50% 1/16W
R711 1-216-821-11 METAL CHIP 1K 5% 1/16W
R712 1-216-845-11 METAL CHIP 100K 5% 1/16W
(EE,E,9E)
R713 1-216-845-11 METAL CHIP 100K 5% 1/16W
(AEP,FR,EE,CEV,CH)
R715 1-216-833-11 RES,CHIP 10K 5% 1/16W
R716 1-216-845-11 METAL CHIP 100K 5% 1/16W
(FX479)
R717 1-216-845-11 METAL CHIP 100K 5% 1/16W
(EXCEPT EE,E,9E)
R718 1-216-845-11 METAL CHIP 100K 5% 1/16W
(US,CND,E,5E,6E,9E)
R719 1-216-845-11 METAL CHIP 100K 5% 1/16W
R721 1-216-845-11 METAL CHIP 100K 5% 1/16W
(FX477)
R722 1-216-821-11 METAL CHIP 1K 5% 1/16W
R723 1-216-821-11 METAL CHIP 1K 5% 1/16W
R724 1-216-821-11 METAL CHIP 1K 5% 1/16W
R725 1-216-821-11 METAL CHIP 1K 5% 1/16W
R726 1-216-833-11 RES,CHIP 10K 5% 1/16W
R727 1-216-833-11 RES,CHIP 10K 5% 1/16W
R728 1-216-833-11 RES,CHIP 10K 5% 1/16W
R729 1-216-833-11 RES,CHIP 10K 5% 1/16W
