– 30 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
< SWITCH >
S701 1-572-922-11 SWITCH, SLIDE (HOLD)
< VIBRATOR >
X701 1-577-262-11 VIBRATOR, CRYSTAL (75kHz)
*************************************************************
A-3021-188-A MAIN BOARD, COMPLETE (FX479:US,CND)
A-3021-190-A MAIN BOARD, COMPLETE
(FX479:AEP,E,CEV,CH)
A-3021-192-A MAIN BOARD, COMPLETE (FX479:EE)
A-3021-195-A MAIN BOARD, COMPLETE (FX479:C&SA)
A-3021-196-A MAIN BOARD, COMPLETE (FX479:FR)
A-3021-197-A MAIN BOARD, COMPLETE (FX477:US,CND)
A-3021-199-A MAIN BOARD, COMPLETE
(FX477:AEP,E,9E,CEV,CH)
A-3021-201-A MAIN BOARD, COMPLETE (FX477:EE)
A-3021-204-A MAIN BOARD, COMPLETE (FX477:C&SA)
A-3021-210-A MAIN BOARD, COMPLETE (FX477:FR)
*********************
3-020-512-01 TERMINAL (-), BATTERY
3-030-022-01 TERMINAL (+), BATTERY
< CAPACITOR >
C1 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V
C2 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V
C4 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C5 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C6 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C7 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C8 1-164-392-11 CERAMIC CHIP 390PF 5% 50V
C10 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C11 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
(EE)
C11 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
(EXCEPT EE)
C12 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C13 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C14 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C15 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C16 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V
C17 1-115-156-11 CERAMIC CHIP 1uF 10V
C18 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C19 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C20 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C21 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EXCEPT US,CND,C&SA)
C21 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
(US,CND,C&SA)
C22 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EXCEPT US,CND,C&SA)
C22 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
(US,CND,C&SA)
C23 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C24 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C25 1-109-935-11 TANTAL. CHIP 4.7uF 20% 4V
C27 1-124-434-00 ELECT 220uF 20% 4V
C28 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C29 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C30 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V
C32 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C33 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V
(US,CND,C&SA)
C34 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C35 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C36 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C51 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C52 1-126-153-11 ELECT 22uF 20% 6.3V
C53 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C101 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C102 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C103 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C104 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C105 1-115-156-11 CERAMIC CHIP 1uF 10V
C106 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C107 1-115-156-11 CERAMIC CHIP 1uF 10V
C108 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C131 1-115-156-11 CERAMIC CHIP 1uF 10V
(FX479)
C132 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
(FX479)
C133 1-164-505-11 CERAMIC CHIP 2.2uF 16V
(FX479)
C201 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C202 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C203 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C204 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C205 1-115-156-11 CERAMIC CHIP 1uF 10V
C206 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C207 1-115-156-11 CERAMIC CHIP 1uF 10V
C208 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C231 1-115-156-11 CERAMIC CHIP 1uF 10V
(FX479)
C232 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
(FX479)
C233 1-164-505-11 CERAMIC CHIP 2.2uF 16V
(FX479)
C301 1-115-156-11 CERAMIC CHIP 1uF 10V
C302 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C303 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C304 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C305 1-124-433-00 ELECT 100uF 20% 4V
C306 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C307 1-164-492-11 CERAMIC CHIP 0.015uF 10% 16V
C308 1-115-156-11 CERAMIC CHIP 1uF 10V
C309 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C310 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C311 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C312 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
