– 31 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
C313 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C331 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
(FX479)
C334 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
(FX479)
C335 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(FX479)
C401 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V
C402 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C403 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C404 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C405 1-126-153-11 ELECT 22uF 20% 6.3V
C406 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C407 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C602 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C603 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C604 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C605 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C606 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C607 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C608 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C609 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C610 1-124-434-00 ELECT 220uF 20% 4V
C731 1-125-622-11 DOUBLE LAYERS 0.1F 5.5V
< FILTER >
CF1 1-781-271-11 FILTER, CERAMIC
CF2 1-781-152-11 FILTER, CERAMIC
< CONNECTOR >
CN301 1-779-079-11 CONNECTOR, BOARD TO BOARD 34P
CN303 1-750-346-21 CONNECTOR, FFC/EPC (ZIF) 6P (FX479:FR)
CN303 1-766-819-11 CONNECTOR, FPC (ZIF) 6P (EXCEPT FX479:FR)
< TRIMMER >
CT1 1-141-463-11 CAP, ADJ 10PF
< DIODE >
D1 8-719-062-15 DIODE KV1430-3/4-TL00
D2 8-719-951-05 DIODE KV1560
D3 8-719-062-15 DIODE KV1430-3/4-TL00
D401 8-719-404-50 DIODE MA111-TX
D402 8-719-056-89 DIODE UDZ-TE-17-12B
D731 8-719-072-70 DIODE MA2ZD14001S0
< FERRITE BEAD >
FB2 1-414-760-21 INDUCTOR, FERRITE BEAD
FB101 1-414-760-21 INDUCTOR, FERRITE BEAD
FB201 1-414-760-21 INDUCTOR, FERRITE BEAD
FB301 1-414-760-21 INDUCTOR, FERRITE BEAD
FB302 1-414-760-21 INDUCTOR, FERRITE BEAD
< FILTER >
FL1 1-236-711-21 FILTER, BAND PASS (EXCEPT EE)
FL1 1-239-813-21 FILTER, BAND PASS (EE)
< IC >
IC1 8-759-564-18 IC A2104AFN(EL)
IC301 8-759-574-69 IC LB8115W-TLM
IC331 8-759-488-80 IC NJM2185AV-TE2 (FX479)
< JACK >
J301 1-565-287-11 JACK (2)
J302 1-750-061-11 JACK, DC (POLARITY UNIFIED TYPE)
(DC IN 3V)
< JUMPER RESISTOR >
JR1 1-216-295-00 SHORT 0
JR2 1-216-295-00 SHORT 0
JR3 1-216-295-00 SHORT 0
JR4 1-216-864-11 METAL CHIP 0 5% 1/16W
JR5 1-216-864-11 METAL CHIP 0 5% 1/16W
JR6 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L1 1-416-596-11 COIL (RF)
L2 1-501-987-11 ANTENNA, FERRITE-ROD (AM)
L3 1-416-595-11 COIL (OSC)
L4 1-415-962-11 COIL (OSC)
L101 1-412-006-31 INDUCTOR CHIP 10uH
L201 1-412-006-31 INDUCTOR CHIP 10uH
L401 1-412-991-11 INDUCTOR 10uH
< PHOTO REFLECTOR >
PH751 8-749-925-05 PHOTO REFLECTOR NJL5183KA-F20-TE1
< TRANSISTOR >
Q2 8-729-602-21 TRANSISTOR 2SC4154-F (US,CND,C&SA)
Q51 8-729-420-24 TRANSISTOR 2SB1218A-QRS
Q52 8-729-402-13 TRANSISTOR XN1501
Q53 8-729-015-76 TRANSISTOR UN5211
Q101 8-729-421-26 TRANSISTOR UN5216
Q201 8-729-421-26 TRANSISTOR UN5216
Q301 8-729-420-24 TRANSISTOR 2SB1218A-QRS
Q302 8-729-015-76 TRANSISTOR UN5211
Q303 8-729-402-13 TRANSISTOR XN1501
Q304 8-729-807-86 TRANSISTOR 2SB1295-UL5
Q305 8-729-015-76 TRANSISTOR UN5211
Q331 8-729-420-53 TRANSISTOR UN5115 (FX479)
Q401 8-729-602-21 TRANSISTOR 2SC4154-F
Q602 8-729-421-26 TRANSISTOR UN5216
Q603 8-729-421-26 TRANSISTOR UN5216
Q604 8-729-141-48 TRANSISTOR 2SB624-BV345
