10 Main camera lens
11 Camera light
12 Second microphone
13 Headset jack
14 Cover for charger/USB port and micro SIM slot
15 NFC™ detection area
16 Wi-Fi/GPS/Bluetooth antenna area
17 Charging dock connector
18 Strap hole
Assembly
A protective plastic sheet is attached to the screen. You should peel off this sheet
before using the touchscreen. Otherwise, the touchscreen might not function
properly.
To insert the micro SIM card
If you insert a micro SIM card while the device is powered on, the device restarts
automatically.
