Sony XR-1800R Service Manual

– 18 –
• Waveforms
– MAIN Board –
1 IC1 8 (X IN)
2 IC1 !¡ (XT IN)
4 IC150 0 (XI)
– KEY Board –
1 IC900 ^º (OSC)
3 IC121 @º (XO)
3.2 Vp-p
125 ns
2 Vp-p
30.5 µ s
3.7 Vp-p
139 ns
2.1 Vp-p
230 ns
2.4 Vp-p
26.6 µ s
