5-5. PRINTED WIRING BOARD – PANEL Section –
– 25 –
– 26 –
XR-1800R
• Semiconductor
Location
Ref. No. Location
D900 B-5
D901 B-5
D902 B-5
D903 B-5
D904 A-5
IC900 A-6
(Page 19)
