Sony XR-1800R Service Manual

– 43 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R350 1-216-095-00 METAL CHIP 82K 5% 1/10W
R351 1-216-095-00 METAL CHIP 82K 5% 1/10W
R352 1-216-075-00 METAL CHIP 12K 5% 1/10W
R353 1-216-073-00 METAL CHIP 10K 5% 1/10W
R354 1-216-023-00 METAL CHIP 82 5% 1/10W
R355 1-216-023-00 METAL CHIP 82 5% 1/10W
R356 1-216-091-00 METAL CHIP 56K 5% 1/10W
R357 1-216-091-00 METAL CHIP 56K 5% 1/10W
R358 1-216-119-00 METAL CHIP 820K 5% 1/10W
R359 1-216-119-00 METAL CHIP 820K 5% 1/10W
R360 1-216-001-00 METAL CHIP 10 5% 1/10W
R361 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R362 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R363 1-249-385-11 CARBON 2.2 5% 1/4W
R364 1-249-385-11 CARBON 2.2 5% 1/4W
R365 1-216-210-00 RES,CHIP 3.3K 5% 1/8W
R366 1-216-073-00 METAL CHIP 10K 5% 1/10W
R450 1-216-150-00 RES,CHIP 10 5% 1/8W
R451 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R452 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R550 1-216-198-00 RES,CHIP 1K 5% 1/8W
R551 1-216-049-11 RES,CHIP 1K 5% 1/10W
R552 1-216-198-00 RES,CHIP 1K 5% 1/8W
R553 1-216-049-11 RES,CHIP 1K 5% 1/10W
R554 1-216-073-00 METAL CHIP 10K 5% 1/10W
R555 1-216-105-00 RES,CHIP 220K 5% 1/10W
R556 1-216-083-00 METAL CHIP 27K 5% 1/10W
R570 1-216-222-00 RES,CHIP 10K 5% 1/8W
R571 1-216-222-00 RES,CHIP 10K 5% 1/8W
R572 1-216-222-00 RES,CHIP 10K 5% 1/8W
R573 1-249-429-11 CARBON 10K 5% 1/4W
R574 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R575 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R576 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R577 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R578 1-216-089-00 RES,CHIP 47K 5% 1/10W
R579 1-216-089-00 RES,CHIP 47K 5% 1/10W
R580 1-216-089-00 RES,CHIP 47K 5% 1/10W
R581 1-216-089-00 RES,CHIP 47K 5% 1/10W
R600 1-216-073-00 METAL CHIP 10K 5% 1/10W
R601 1-216-222-00 RES,CHIP 10K 5% 1/8W
R602 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R603 1-216-089-00 RES,CHIP 47K 5% 1/10W
R604 1-216-097-00 RES,CHIP 100K 5% 1/10W
R605 1-216-105-00 RES,CHIP 220K 5% 1/10W
R606 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R607 1-216-089-00 RES,CHIP 47K 5% 1/10W
R608 1-216-073-00 METAL CHIP 10K 5% 1/10W
R609 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R610 1-216-073-00 METAL CHIP 10K 5% 1/10W
R611 1-216-041-00 METAL CHIP 470 5% 1/10W
R612 1-216-073-00 METAL CHIP 10K 5% 1/10W
R613 1-216-198-00 RES,CHIP 1K 5% 1/8W
R614 1-216-081-00 METAL CHIP 22K 5% 1/10W
R615 1-216-073-00 METAL CHIP 10K 5% 1/10W
R616 1-249-421-11 CARBON 2.2K 5% 1/4W
R620 1-216-097-00 RES,CHIP 100K 5% 1/10W
R621 1-216-081-00 METAL CHIP 22K 5% 1/10W
R622 1-216-206-00 RES,CHIP 2.2K 5% 1/8W
R623 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R624 1-216-089-00 RES,CHIP 47K 5% 1/10W
R625 1-249-482-11 CARBON 4.7 5% 1/2W
R626 1-216-073-00 METAL CHIP 10K 5% 1/10W
R627 1-249-482-11 CARBON 4.7 5% 1/2W
< VARIABLE RESISTOR >
RV100 1-241-768-11 RES, ADJ, CARBON 220K
< SWITCH >
S2 1-771-531-11 SWITCH, TACTILE (RESET)
< TUNER >
TU100 1-693-423-21 FM/AM TUNER UNIT
< VIBRATOR >
X1 1-579-952-21 VIBRATOR, CERAMIC (8MHz)
X2 1-567-098-61 VIBRATOR, CRYSTAL (32.768kHz)
X100 1-567-848-11 VIBRATOR, CRYSTAL (7.2MHz)
X150 1-579-242-41 VIBRATOR, CRYSTAL (4.332MHz)
************************************************************
MISCELLANEOUS
**************
12 1-776-527-31 CORD (WITH CONNECTOR) (ISO) (POWER)
F901 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) (10A)
HP901 1-543-717-11 HEAD, MAGNETIC (PLAYBACK)
M901 X-3364-496-1 MOTOR ASSY (CAPSTAN/REEL)
S901 1-692-502-11 SWITCH, SLIDE (DIRECTION)
S902 1-692-065-11 SWITCH, LEAF (FF/REW)
S903 1-554-790-21 SWITCH, POWER (TAPE DETECT)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
3-864-874-11 MANUAL, INSTRUCTION (ENGLISH, SPANISH,
SWEDISH, PORTUGUESE) (AEP, UK)
3-864-874-31 MANUAL, INSTRUCTION (ENGLISH, POLISH,
CZECK, GREEK,TURKISH) (AEP, SE)
3-864-874-41 MANUAL, INSTRUCTION (GERMAN) (G)
3-864-875-11 MANUAL, INSTRUCTION, INSTALL (ENGLISH,
SPANISH, SWEDISH, PORTUGUESE) (AEP, UK)
3-864-875-21 MANUAL, INSTRUCTION, INSTALL (FRENCH,
ITALIAN, GERMAN, DUTCH) (AEP, G, SE)
3-864-875-31 MANUAL, INSTRUCTION, INSTALL (ENGLISH,
POLISH, CZECK, GREEK, TURKISH) (AEP, SE)
X-3372-595-1 CASE ASSY (for FRONT PANEL) (SE)
************************************************************
**************
HARDWARE LIST
**************
#1 7-621-772-10 SCREW +B 2X4
#2 7-685-792-09 SCREW +PTT 2.6X6 (S)
#3 7-685-793-09 SCREW +PTT 2.6X8 (S)
#4 7-685-790-01 SCREW +PTT 2.6X4 (S)
#5 7-685-105-19 TPG +P 2X8 TYPE2, NON-SLIT
