Smart Core
Red LED blinking
count
Error Name Retry Permission Times
*1
Note
2x MAIN_POWER
STDWN_RTRY_LIMIT_MAINPOWR = 1
3x
DC_ALERT (5V) STDWN_RTRY_LIMIT = 2
AUD_ERR STDWN_RTRY_LIMIT = 2
4x
LD_ERR STDWN_RTRY_LIMIT = 2
BCM_ERR STDWN_RTRY_LIMIT = 2
5x P_ID_ERR STDWN_RTRY_LIMIT = 2
6x BACKLIGHT STDWN_RTRY_LIMIT = 2
7x TEMP_ERR STDWN_RTRY_LIMIT = 2
8x 4KBE_ERR STDWN_RTRY_LIMIT = 2
14
Number of off/on action during the
error shutdown is recorded to
STDWN_OFFON_CNT
*2
.
Number of off/on action for MAIN_POWER
shutdown is recorded to
STDWN_OFFON_CNT_MAIN_POWER
*2
.
*1) If STDWN_OFFON_CNT <= STDWN_RTRY_LIMIT, and STDWN_OFFON_CNT_MAIN_POWER <= STDWN_RTRY_LIMIT_MAINPOWR, you can turn the set on
by a remote/power key. At this time, if the error occurs again, the STDWN_OFFON_CNT is incremented by 1.
*2) When the main micro operates normally for STDWN_OFFON_CLR = 60 minutes, STDWN_OFFON_CNT and STDWN_OFFON_CNT_MAIN_POWER are cleared.
Retry Limitation by Remote/Power Key
SELF DIAGNOSIS FUNCTION
SYSSET
2023/11/2806:39:49(GMT+09:00)
To Next Page
