SET PART LIST
23
REF.
NO
PART NO. DESCRIPTION
XR-55A80K
XR-
55A80CK
UCM LA8 UC2
1
5-039-876-01
LABEL, SIDE TERMINAL HP (TGR)
• n/a •
1 5-039-876-21
LABEL, SIDE TERMINAL HP (TGR)
n/a • n/a
2 4-745-608-01
AC COVER (AT)
n/a • n/a
3
5-033-671-01
BTM COVER BARE (COM SEP)
• • •
4
5-033-669-01
TERMINAL COVER (COM SEP)
• • •
5 5-036-202-01
REAR COVER (L SEP) A
• n/a •
5 5-036-202-51
REAR COVER (L SEP) A
n/a • n/a
6 5-039-955-11
BRACKET SIDE (BNN) A
• n/a •
6 5-039-955-01
BRACKET SIDE (BNN) A
n/a • n/a
7
1-013-469-11
SP-BOX ASSY,FY22 W40L-A
• • •
8
1-013-469-21
SP-BOX ASSY,FY22 W40L-B
• • •
9
5-009-258-21
BRACKET, WIFI(BNN)
• • •
10
1-005-419-13
WLAN/BT MODULE(11AC)
• • •
11
A-5042-804-A COMPL_SVC_BM5STY_UC_FS
• n/a •
11
A-5042-807-A COMPL_SVC_BM5STY_LABR_FS
n/a • n/a
12
4-457-451-12
SHEET, THERMAL (BAF)
• • •
13
1-013-507-22
G25BP-STATIC CONVERTER (TV)
• n/a •
13
1-013-507-12
G25B-STATIC CONVERTER (TV)
n/a • n/a
TOOLS & EQUIPMENTS FFC PRECAUTIONS SECTION 1 SECTION 2 SECTION 3 SMART CORE APPENDIX
1-4. EXPLODED VIEW AND PART LIST
SECTION 1: XR-55A8*K
REF.
NO
PART NO. DESCRIPTION
XR-55A80K
XR-
55A80CK
UCM LA8 UC2
14 5-035-920-11
SHEET, INSULATION (L SEP) A
• n/a •
14 5-035-586-11
SHEET, INSULATION (L SEP)
n/a • n/a
15
A-5044-454-A P-MOD (YDCM055UNG01)(SVC)
• • n/a
16
5-034-379-01
STAND L (2L SEP) A
• • •
17
5-034-380-01
STAND R (2L SEP) A
• • •
