3. Unhook the bottom hook, starting from center.(4 hooks)
28
REAR COVER
TOOLS & EQUIPMENTS FFC PRECAUTIONS SECTION 1 SECTION 2 SECTION 3 SMART CORE APPENDIX
‹1›
‹2›
‹
2›
※bottom view
1
Legend
=bottom hook
① Pull rear cover bottom center until hook
release sound is heard.
② Pull rear cover towards outside direction
until hook release sound is heard.
※bottom view
<left>
2
<right>
2-1. DISASSEMBLY AND REMOVAL CAUTION
