Sony XR-55A80K - FFC Precautions

6
ESSENTIAL CAUTION INFO THAT MUST BE FOLLOWED BY PRODUCTION FOR ANY FFC INSERTION METHOD
Connector
FFC
OK
STRAIGHT INSERT
Connector
FFC
FFC
Connector
FFC
BOARD
Cross section of TV set from A
INSERT FFC IN
STRAIGHT CONDITION
DO NOT INSERT FFC IN
SLANTING CONDITION
DO NOT APPLY EXCESSIVE
FORCE DURING INSERTION
INSERT ANGLE
FFC
Connector
OK
NG
NG
FFC bending
For manual insertion
checking
For automation
insertion checking
INDICATION FOR FFC FULL INSERTION
RECOMMENDED FFC HOLDING METHOD MATRIX
FFC PRECAUTIONS
FFC Insertion Method
2A
1A
1B
1C
2C
TOOLS & EQUIPMENTS FFC PRECAUTIONS SECTION 1 SECTION 2 SECTION 3 SMART CORE APPENDIX
