Sony XR-C5300X Service Manual

35
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SECTION 9
ELECTRICAL PARTS LIST
* 1-676-603-11 SUB BOARD
**********
1-792-195-11 CABLE, FLEXIBLE FLAT
< CONNECTOR >
CNP801 1-794-064-11 SOCKET, CONNECTOR 14P
< DIODE >
LED801 8-719-038-07 DIODE CL-190PG-CD-T (C5305)
LED801 8-719-061-16 DIODE CL-190SR-CD-T (C5300X,C5600X)
< SWITCH >
LSW801 1-771-609-11 SWITCH, TACT (WITH LED)(A)(C5305)
LSW801 1-771-883-21 SWITCH, TACTILE (WITH LED)(A)
(C5300X,C5600X)
************************************************************
* A-3326-145-A MAIN BOARD, COMPLETE (C5600X)
*****************************
* A-3326-165-A MAIN BOARD, COMPLETE (C5300X)
*****************************
* A-3326-176-A MAIN BOARD, COMPLETE (C5305)
*****************************
* 3-040-996-11 HEAT SINK (2P)
* 3-040-998-01 BRACKET (IC)
* 3-041-262-01 HEAT SINK (REG/XR)
7-685-647-11 SCREW +BVTP 3X10 TYPE2 N-S
7-685-793-01 SCREW +PTT 2.6X8 (S)
7-685-795-01 SCREW +PTT 2.6X12 (S)
< CAPACITOR >
C1 1-163-233-11 CERAMIC CHIP 18PF 5.00% 50V
C2 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C3 1-104-664-11 ELECT 47UF 20.00% 16V
C5 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C6 1-104-664-11 ELECT 47UF 20.00% 16V
C8 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C11 1-109-982-11 CERAMIC CHIP 1UF 10.00% 10V
C13 1-109-982-11 CERAMIC CHIP 1UF 10.00% 10V
C21 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C22 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C23 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C31 1-124-233-11 ELECT 10UF 20.00% 16V
C41 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C44 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C52 1-124-234-00 ELECT 22uF 20% 16V
C101 1-163-263-11 CERAMIC CHIP 330PF 5.00% 50V
C102 1-163-263-11 CERAMIC CHIP 330PF 5.00% 50V
C103 1-163-021-11 CERAMIC CHIP 0.01UF 10.00% 50V
C104 1-164-489-11 CERAMIC CHIP 0.22UF 10.00% 16V
C105 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C106 1-109-982-11 CERAMIC CHIP 1UF 10.00% 10V
C109 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C110 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C111 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C112 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C141 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C142 1-163-181-00 CERAMIC CHIP 100PF 5.00% 50V
C171 1-164-506-11 CERAMIC CHIP 4.7UF 16V
C172 1-163-181-00 CERAMIC CHIP 100PF 5.00% 50V
C174 1-164-489-11 CERAMIC CHIP 0.22UF 10.00% 16V
C181 1-164-506-11 CERAMIC CHIP 4.7UF 16V
C182 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C183 1-163-181-00 CERAMIC CHIP 100PF 5.00% 50V
C184 1-164-489-11 CERAMIC CHIP 0.22UF 10.00% 16V
C191 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C201 1-163-263-11 CERAMIC CHIP 330PF 5.00% 50V
C202 1-163-263-11 CERAMIC CHIP 330PF 5.00% 50V
C203 1-163-021-11 CERAMIC CHIP 0.01UF 10.00% 50V
C204 1-164-489-11 CERAMIC CHIP 0.22UF 10.00% 16V
C205 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C206 1-109-982-11 CERAMIC CHIP 1UF 10.00% 10V
C209 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C210 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C211 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C212 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C241 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C242 1-163-181-00 CERAMIC CHIP 100PF 5.00% 50V
C271 1-164-506-11 CERAMIC CHIP 4.7UF 16V
C272 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C274 1-164-489-11 CERAMIC CHIP 0.22UF 10.00% 16V
C281 1-164-506-11 CERAMIC CHIP 4.7UF 16V
C282 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C283 1-163-181-00 CERAMIC CHIP 100PF 5.00% 50V
C284 1-164-489-11 CERAMIC CHIP 0.22UF 10.00% 16V
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Due to standardization, replacements in the parts
list may be different from the parts specified in
the diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
Note:
When indicating parts by reference
number, please include the board
name.
SUB MAIN
