Sony XR-C5300X Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
36
C301 1-124-234-00 ELECT 22uF 20% 16V
C302 1-131-353-00 TANTALUM 10uF 10% 35V
C303 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C304 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C305 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C306 1-163-021-11 CERAMIC CHIP 0.01UF 10.00% 50V
C307 1-163-021-11 CERAMIC CHIP 0.01UF 10.00% 50V
C331 1-163-263-11 CERAMIC CHIP 330PF 5.00% 50V
C332 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C333 1-163-021-11 CERAMIC CHIP 0.01UF 10.00% 50V
C335 1-124-233-11 ELECT 10UF 20.00% 16V
C336 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C337 1-124-584-00 ELECT 100uF 20% 10V
C340 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C341 1-163-181-00 CERAMIC CHIP 100PF 5.00% 50V
C351 1-165-319-11 CERAMIC CHIP 0.1UF 50V
C352 1-165-319-11 CERAMIC CHIP 0.1UF 50V
C353 1-163-031-11 CERAMIC CHIP 0.01UF 50V
C354 1-124-233-11 ELECT 10UF 20.00% 16V
C355 1-124-234-00 ELECT 22uF 20% 16V
C356 1-126-934-11 ELECT 220UF 20.00% 16V
C357 1-165-319-11 CERAMIC CHIP 0.1UF 50V
C358 1-163-031-11 CERAMIC CHIP 0.01UF 50V
C501 1-124-589-11 ELECT 47uF 20% 16V
C502 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C503 1-163-227-11 CERAMIC CHIP 10PF 5.00% 50V
C504 1-163-227-11 CERAMIC CHIP 10PF 5.00% 50V
C505 1-163-234-11 CERAMIC CHIP 20PF 5.00% 50V
C506 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
C508 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C509 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C511 1-163-021-11 CERAMIC CHIP 0.01UF 10.00% 50V
C551 1-125-710-11 DOUBLE LAYER 0.1F 5.5V
C552 1-104-665-11 ELECT 100UF 20.00% 10V
C553 1-109-982-11 CERAMIC CHIP 1UF 10.00% 10V
C556 1-165-319-11 CERAMIC CHIP 0.1UF 50V
C571 1-126-163-11 ELECT 4.7uF 20% 50V
C581 1-164-506-11 CERAMIC CHIP 4.7UF 16V
C582 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C584 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C601 1-164-346-11 CERAMIC CHIP 1UF 16V
C602 1-164-346-11 CERAMIC CHIP 1UF 16V
C611 1-124-233-11 ELECT 10UF 20.00% 16V
C612 1-124-233-11 ELECT 10UF 20.00% 16V
C614 1-124-233-11 ELECT 10UF 20.00% 16V
C615 1-124-233-11 ELECT 10UF 20.00% 16V
C616 1-124-233-11 ELECT 10UF 20.00% 16V
C617 1-124-233-11 ELECT 10UF 20.00% 16V
C618 1-164-506-11 CERAMIC CHIP 4.7UF 16V
C621 1-164-489-11 CERAMIC CHIP 0.22UF 10.00% 16V
C622 1-124-589-11 ELECT 47uF 20% 16V
C623 1-164-506-11 CERAMIC CHIP 4.7UF 16V
C701 1-163-059-00 CERAMIC CHIP 0.01UF 10.00% 50V
C702 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C703 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C704 1-163-047-11 CERAMIC CHIP 0.001uF 5% 50V
C705 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C752 1-107-682-11 CERAMIC CHIP 1UF 10.00% 16V
C753 1-164-506-11 CERAMIC CHIP 4.7UF 16V
C755 1-124-233-11 ELECT 10UF 20.00% 16V
C756 1-164-506-11 CERAMIC CHIP 4.7UF 16V
C758 1-109-982-11 CERAMIC CHIP 1UF 10.00% 10V
C781 1-107-885-31 ELECT 3300UF 20.00% 16V
C782 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C783 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C784 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C785 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
(C5600X)
< CONNECTOR >
CN301 1-766-260-11 CONNECTOR, FFC/FPC (ZIF) 7P
* CN351 1-506-995-11 PIN, CONNECTOR (PC BOARD) 13P
CN581 1-580-907-31 PLUG, CONNECTOR (BUS CONTROL IN)
CN701 1-784-456-11 CONNECTOR, FFC/FPC 14P
CN781 1-774-701-11 PIN, CONNECTOR 16P (POWER CONNECTOR)
< DIODE >
D1 8-719-420-51 DIODE MA729-TX
D31 8-719-422-12 DIODE UDZ-TE-17-3.9B
D51 8-719-420-51 DIODE MA729-TX
D351 8-719-977-22 DIODE UDZ-TE-17-9.1B
D352 8-719-970-02 DIODE 1SR139-400T-32
D501 8-719-400-20 DIODE MA152WA-TX
D551 8-719-400-20 DIODE MA152WA-TX
D552 8-719-073-01 DIODE MA111-TX
D553 8-719-073-01 DIODE MA111-TX
D554 8-719-072-70 DIODE MA2ZD14001S0
D571 8-719-057-80 DIODE MA8180-M-TX
D572 8-719-420-14 DIODE MA8082-M(TX)
D581 8-719-057-80 DIODE MA8180-M-TX
D582 8-719-017-62 DIODE MA8068-L-TX
D583 8-719-056-82 DIODE UDZ-TE-17-6.2B
D584 8-719-057-80 DIODE MA8180-M-TX
D585 8-719-072-70 DIODE MA2ZD14001S0
D586 8-719-057-80 DIODE MA8180-M-TX
D587 8-719-911-19 DIODE 1SS119-25TD
D588 8-719-911-19 DIODE 1SS119-25TD (C5600X)
D601 8-719-423-23 DIODE MA8110-M-TX
D610 8-719-970-02 DIODE 1SR139-400T-32
D611 8-719-970-02 DIODE 1SR139-400T-32
D613 8-719-970-02 DIODE 1SR139-400T-32
D614 8-719-970-02 DIODE 1SR139-400T-32
D621 8-719-422-12 DIODE UDZ-TE-17-3.9B
D622 8-719-073-01 DIODE MA111-TX
D624 8-719-422-97 DIODE MA8091-H-TX
D701 8-719-035-74 DIODE MA4062-M(TA)
D702 8-719-035-74 DIODE MA4062-M(TA)
D703 8-719-977-12 DIODE MA8068-M-TX
D704 8-719-977-12 DIODE MA8068-M-TX
D705 8-719-056-82 DIODE UDZ-TE-17-6.2B
D706 8-719-423-23 DIODE MA8110-M-TX
D707 8-719-056-82 DIODE UDZ-TE-17-6.2B
D708 8-719-056-82 DIODE UDZ-TE-17-6.2B
D709 8-719-056-82 DIODE UDZ-TE-17-6.2B
D710 8-719-056-82 DIODE UDZ-TE-17-6.2B
D781 8-719-049-38 DIODE 1N5404TU
MAIN
