Sony XR-C5300X Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
37
< IC >
IC301 8-752-079-78 IC CXA2509AQ-T4
IC331 8-759-653-27 IC TDA7402TR
IC351 8-759-527-33 IC LB1930M-TLM
IC501 8-759-663-32 IC MN101C49KTA
IC551 8-759-574-61 IC XC61AN4302MR
IC581 8-759-449-89 IC BA8270F-E2
IC611 8-759-661-47 IC BA4908-V3
IC751 8-759-663-88 IC TA8268H
< JACK >
J1 1-764-808-21 JACK (FM/AM ANTENNA)
J331 1-774-699-12 JACK, PIN 4P
(BUS AUDIO IN, AUDIO OUT REAR)
J561 1-566-822-41 JACK (REMOTE IN)
< JUMPER RESISTOR >
JC31 1-216-295-00 SHORT 0
JC51 1-216-295-00 SHORT 0
JC171 1-216-295-00 SHORT 0
JC181 1-216-295-00 SHORT 0
JC191 1-216-295-00 SHORT 0
JC192 1-216-296-00 SHORT 0
JC193 1-216-296-00 SHORT 0
JC194 1-216-295-00 SHORT 0
JC195 1-216-296-00 SHORT 0
JC271 1-216-295-00 SHORT 0
JC281 1-216-295-00 SHORT 0
JC282 1-216-295-00 SHORT 0
JC283 1-216-296-00 SHORT 0
JC301 1-216-295-00 SHORT 0
JC302 1-216-295-00 SHORT 0
JC303 1-216-295-00 SHORT 0
JC304 1-216-295-00 SHORT 0
JC351 1-216-295-00 SHORT 0
JC502 1-216-295-00 SHORT 0
JC503 1-216-295-00 SHORT 0
JC504 1-216-295-00 SHORT 0
JC507 1-216-295-00 SHORT 0
JC581 1-216-295-00 SHORT 0
JC582 1-216-295-00 SHORT 0
JC583 1-216-296-00 SHORT 0
< COIL >
L51 1-410-750-41 INDUCTOR 0.47uH
L501 1-410-750-41 INDUCTOR 0.47uH
L781 1-419-476-11 INDUCTOR 250uH
< TRANSISTOR >
Q11 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q21 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q31 8-729-020-67 TRANSISTOR XN1A312-TX
Q171 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q181 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q271 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q281 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q351 8-729-015-11 TRANSISTOR 2SD1802FAST-TL
Q352 8-729-020-67 TRANSISTOR XN1A312-TX
Q353 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q354 8-729-106-60 TRANSISTOR 2SB1132-T100-R
Q551 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q571 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q581 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q582 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q583 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR (C5600X)
Q601 8-729-423-99 TRANSISTOR 2SD2137-OP-TA
Q602 8-729-020-67 TRANSISTOR XN1A312-TX
Q621 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q622 8-729-021-94 TRANSISTOR 2SK1657-T1B
Q631 8-729-020-67 TRANSISTOR XN1A312-TX
< RESISTOR >
R1 1-216-025-00 RES-CHIP 100 5% 1/10W
R2 1-216-025-00 RES-CHIP 100 5% 1/10W
R4 1-216-295-00 SHORT 0
R5 1-216-295-00 SHORT 0
R11 1-216-295-00 SHORT 0
R12 1-216-089-00 RES-CHIP 47K 5% 1/10W
R21 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R22 1-216-085-00 METAL CHIP 33K 5% 1/10W
R31 1-216-001-00 METAL CHIP 10 5% 1/10W
R32 1-216-037-00 METAL CHIP 330 5% 1/10W
R101 1-216-041-00 METAL CHIP 470 5% 1/10W
R102 1-216-109-00 METAL CHIP 330K 5% 1/10W
R103 1-216-077-00 RES-CHIP 15K 5% 1/10W
R104 1-216-079-00 METAL CHIP 18K 5% 1/10W
R141 1-216-073-00 METAL CHIP 10K 5% 1/10W
R142 1-216-025-00 RES-CHIP 100 5% 1/10W
R171 1-216-025-00 RES-CHIP 100 5% 1/10W
R172 1-216-081-00 METAL CHIP 22K 5% 1/10W
R173 1-216-025-00 RES-CHIP 100 5% 1/10W
R175 1-216-085-00 METAL CHIP 33K 5% 1/10W
R181 1-216-025-00 RES-CHIP 100 5% 1/10W
R182 1-216-081-00 METAL CHIP 22K 5% 1/10W
R183 1-216-025-00 RES-CHIP 100 5% 1/10W
R185 1-216-085-00 METAL CHIP 33K 5% 1/10W
R191 1-216-089-00 RES-CHIP 47K 5% 1/10W
R192 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R201 1-216-041-00 METAL CHIP 470 5% 1/10W
R202 1-216-109-00 METAL CHIP 330K 5% 1/10W
R203 1-216-077-00 RES-CHIP 15K 5% 1/10W
R204 1-216-079-00 METAL CHIP 18K 5% 1/10W
R241 1-216-073-00 METAL CHIP 10K 5% 1/10W
R242 1-216-025-00 RES-CHIP 100 5% 1/10W
R271 1-216-025-00 RES-CHIP 100 5% 1/10W
R272 1-216-081-00 METAL CHIP 22K 5% 1/10W
R273 1-216-025-00 RES-CHIP 100 5% 1/10W
R275 1-216-085-00 METAL CHIP 33K 5% 1/10W
R281 1-216-025-00 RES-CHIP 100 5% 1/10W
R282 1-216-081-00 METAL CHIP 22K 5% 1/10W
R283 1-216-025-00 RES-CHIP 100 5% 1/10W
R285 1-216-085-00 METAL CHIP 33K 5% 1/10W
R301 1-208-812-11 RES-CHIP 18K 2% 1/10W
R302 1-216-097-00 RES-CHIP 100K 5% 1/10W
R303 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
MAIN
