– 13 –
MAIN BOARD, HEAT SINK
4
main board
2
three ground point
screws
1
connector
(CN553)
1
connector
(J10)
5
screw
(PTT2.6
×
10)
3
screw
(PTT2.6
×
10)
7
screw
(PTT2.6
×
10)
9
seven screws
(PTT2.6
×
10)
8
cord (with connector)
(ANT)
6
inverter ass’y
3
screw
(PTT2.6
×
10)
0
heat sink
