Sony XR-C7220R Service Manual

– 61 –
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
INVERTER KEY
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
When indicating parts by reference
number, please include the board.
* A-3313-646-A INVERTER BOARD, COMPLETE
*************************
< CAPACITOR >
C551 1-126-157-11 ELECT 10uF 20% 16V
C552 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C553 1-126-934-11 ELECT 220uF 20% 10V
C554 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C555 1-124-257-00 ELECT 2.2uF 20% 50V
C556 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C557 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CN550 1-564-507-11 PLUG, CONNECTOR 4P
* CN551 1-564-505-11 PLUG, CONNECTOR 2P
< DIODE >
D550 8-719-422-49 DIODE MA8056-L
D551 8-719-422-80 DIODE MA8075-H-TX
D552 8-719-404-50 DIODE MA111-TX
D553 8-719-033-43 DIODE RB751H
D554 8-719-422-49 DIODE MA8056-L
< IC >
IC550 8-759-495-75 IC NJM317F
< TRANSISTOR >
Q552 8-729-421-22 TRANSISTOR UN2211
Q553 8-729-026-68 TRANSISTOR 2SD2525 (TP)
Q554 8-729-421-22 TRANSISTOR UN2211
Q555 8-729-903-46 TRANSISTOR 2SB1132-P
Q556 8-729-016-11 TRANSISTOR 2SD1507M
Q557 8-729-021-94 FET 2SK1657-T1B
< RESISTOR >
R552 1-216-198-00 RES,CHIP 1K 5% 1/8W
R553 1-216-198-00 RES,CHIP 1K 5% 1/8W
R555 1-216-158-00 RES,CHIP 22 5% 1/8W
R556 1-216-158-00 RES,CHIP 22 5% 1/8W
R557 1-216-001-00 METAL CHIP 10 5% 1/10W
R558 1-216-097-00 RES,CHIP 100K 5% 1/10W
R559 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R560 1-216-063-00 RES,CHIP 3.9K 5% 1/10W
R561 1-216-180-00 RES,CHIP 180 5% 1/8W
R562 1-216-097-00 RES,CHIP 100K 5% 1/10W
R563 1-216-097-00 RES,CHIP 100K 5% 1/10W
< TRANSFORMER >
T550 1-431-831-11 TRANSFORMER, OSCILLATION (EL)
************************************************************
KEY BOARD
**********
1-694-414-11 CONDUCTOR BOARD, CONNECTION
3-017-984-01 TAPE (EL), DOUBLE STICK
* 3-022-326-03 PLATE (LCD), LIGHT GUIDE
* 3-022-327-01 PLATE (LCD), GROUND
3-023-554-01 SHEET (EL), ADHESIVE
* 3-034-558-01 ILLUMINATOR (LCD)
3-327-119-01 SPACER (A)
< CAPACITOR >
C900 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C901 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C902 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C903 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C904 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C905 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN900 1-778-183-11 PLUG, CONNECTOR 18P
< DIODE >
D901 8-719-420-90 DIODE MA8051-M
D903 8-719-420-90 DIODE MA8051-M
< EL LUMINOUS ELEMENT >
EL900 1-517-766-11 LIGHT, ELECTRO LUMINESCENT
< COIL >
FB901 1-414-233-22 INDUCTOR CHIP 0uH
< IC >
IC900 8-759-496-75 IC uPD16432BGC-018-9EU
