Sony ZSS2IPW - Main Board Components

46
ZS-S2iP
R440 1-216-809-11 METAL CHIP 100 5% 1/10W
R441 1-216-817-11 METAL CHIP 470 5% 1/10W
R442 1-216-821-11 METAL CHIP 1K 5% 1/10W
R443 1-216-817-11 METAL CHIP 470 5% 1/10W
R444 1-216-817-11 METAL CHIP 470 5% 1/10W
< SWITCH >
S401 1-786-050-21 SWITCH, KEYBOARD (TUNE –)
S403 1-786-050-21 SWITCH, KEYBOARD (x)
S404 1-786-050-21 SWITCH, KEYBOARD (u)
S407 1-786-050-21 SWITCH, KEYBOARD (POWER)
S408 1-786-050-21 SWITCH, KEYBOARD (SLEEP)
S410 1-786-050-21 SWITCH, KEYBOARD (TUNE +)
S411 1-786-050-21 SWITCH, KEYBOARD (./PRESET –)
S412 1-786-050-21 SWITCH, KEYBOARD (>/PRESET +)
S413 1-786-050-21 SWITCH, KEYBOARD (DISPLAY)
S414 1-786-050-21 SWITCH, KEYBOARD (MODE)
S417 1-786-050-21 SWITCH, KEYBOARD (MEGA BASS)
*************************************************************
A-1336-409-A DOCK BOARD, COMPLETE
*********************
< CAPACITOR >
C1008 1-128-392-11 ELECT CHIP 470uF 20% 6.3V
C1009 1-128-392-11 ELECT CHIP 470uF 20% 6.3V
< CONNECTOR >
CN810 1-820-701-11 PIN, CONNECTOR 30P
CN811 1-821-662-21 CONNECTOR, FFC/FPC 15P
< JUMPER RESISTOR >
FB181 1-216-864-11 SHORT CHIP 0
FB281 1-216-864-11 SHORT CHIP 0
FB1001 1-216-295-11 SHORT CHIP 0
FB1002 1-216-295-11 SHORT CHIP 0
FB1003 1-216-295-11 SHORT CHIP 0
FB1004 1-216-864-11 SHORT CHIP 0
< COIL >
L1001 1-456-437-21 COIL, CHOKE 100uH
< RESISTOR >
R1009 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R1010 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R1011 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R1012 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R1013 1-216-864-11 SHORT CHIP 0
R1014 1-216-864-11 SHORT CHIP 0
R1015 1-216-864-11 SHORT CHIP 0
R1016 1-218-885-11 METAL CHIP 39K 0.5% 1/10W
R1019 1-218-912-11 METAL CHIP 510K 0.5% 1/10W
R1021 1-218-892-11 METAL CHIP 75K 0.5% 1/10W
R1026 1-218-892-11 METAL CHIP 75K 0.5% 1/10W
*************************************************************
HP BOARD
*********
< CAPACITOR >
C116 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C216 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN308 1-815-445-11 PIN, CONNECTOR (PWB) 4P
< JACK >
J321 1-815-325-11 JACK (i)
< RESISTOR >
R146 1-216-809-11 METAL CHIP 100 5% 1/10W
R148 1-216-805-11 METAL CHIP 47 5% 1/10W
R246 1-216-809-11 METAL CHIP 100 5% 1/10W
R248 1-216-805-11 METAL CHIP 47 5% 1/10W
*************************************************************
KEY (FUNC) BOARD
****************
< RESISTOR >
R413 1-216-813-11 METAL CHIP 220 5% 1/10W
R418 1-216-813-11 METAL CHIP 220 5% 1/10W
R419 1-216-817-11 METAL CHIP 470 5% 1/10W
R424 1-216-817-11 METAL CHIP 470 5% 1/10W
R435 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S402 1-786-050-21 SWITCH, KEYBOARD
(RADIO/BAND/AUTO PRESET)
S405 1-786-050-21 SWITCH, KEYBOARD (CD)
S415 1-786-050-21 SWITCH, KEYBOARD (iPod)
S419 1-786-050-21 SWITCH, KEYBOARD (AUDIO)
*************************************************************
KEY (VOL) BOARD
***************
< CONNECTOR >
CN401 1-815-550-11 PIN, CONNECTOR (PWB) 2P
< RESISTOR >
R422 1-216-833-11 METAL CHIP 10K 5% 1/10W
R432 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R437 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S416 1-786-050-21 SWITCH, KEYBOARD (VOLUME –)
S418 1-786-050-21 SWITCH, KEYBOARD (VOLUME +)
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
KEY (FUNC) KEY (VOL)HPCONTROL DOCK
