SoundCraft LX7-2 User Manual

1 - 6
IMPORTANTSAFETYWARNINGS
THISUNITMUSTBEEARTHED
Undernocircumstancesshouldthemainsearthbedisconnectedfromthe
mainslead.
The wires in the mains lead are coloured in accordance with the following code:
Earth: Green and Yellow (Green/Yellow - US)
Neutral: Blue (White - US)
Live: Brown (Black - US)
As the colours of the wires in the mains lead may not correspond with the coloured markings identifying the terminals in your plug,
proceed as follows:
The wire which is coloured Green and Yellow must be connected to the terminal in the plug which is marked with the letter
E or by the earth symbol.
The wire which is coloured Blue must be connected to the terminal in the plug which is marked with the letter N.
The wire which is coloured Brown must be connected to the terminal in the plug which is marked with the letter L.
Ensure that these colour codings are followed carefully in the event of the plug being changed.
Toavoidtheriskoffire,replacethemainsfuseonlywiththecorrectvalue
fuse,asmarkedontherearpanel.
Theinternalpowersupplyunitcontainsnouserserviceableparts.Refer
allservicingtoaqualifiedserviceengineer,throughtheappropriate
Soundcraftdealer.
