LX7-II Spare Parts Page 3 - 7
LX7II 16I/P FRONT PNL ASSY RS2282
Ident Description Part Number
--- LX7II 16IP FRONT PNL P-S2013A-03
--- LX7II MID SUPPORT P-S2013D-02
--- LX7II I/P PCB ASSY R-S2011A-03-AF
--- LX7II MASTER+I/P PCB ASSY R-S2011C-04-AF
--- LX7II MASTER UPPER LINK PCB AS R-S2011G-01-AF
--- LX7II MASTER LOWER LINK PCB AS R-S2011H-01-AF
LX7II 16I/P REAR PNL ASSY RS2283
Ident Description Part Number
--- LX7II 16IP REAR PNL P-S2013B-02
--- LX7II RR CON PCB ASSY R-S2011B-02-AF
--- LX7II MASTER+RR CON PCB ASSY R-S2011D-02-AF
LX7II 24I/P FRONT PNL ASSY RS2284
Ident Description Part Number
--- LX7II MID SUPPORT P-S2013D-02
--- LX7II 24IP FRONT PNL P-S2014A-05
--- LX7II I/P PCB ASSY R-S2011A-03-AF
--- LX7II MASTER+I/P PCB ASSY R-S2011C-04-AF
--- LX7II MASTER UPPER LINK PCB AS R-S2011G-01-AF
--- LX7II MASTER LOWER LINK PCB AS R-S2011H-01-AF
--- LX7II INPUT UPPER LINK PCB ASS R-S2011J-01-AF
--- LX7II INPUT LOWER LINK PCB ASS R-S2011K-01-AF
LX7II 24I/P REAR PNL ASSY RS2285
Ident Description Part Number
--- LX7II 24IP REAR PNL P-S2014B-02
--- LX7II RR CON PCB ASSY R-S2011B-02-AF
--- LX7II MASTER+RR CON PCB ASSY R-S2011D-02-AF
LX7II 32I/P FRONT PNL ASSY RS2286
Ident Description Part Number
--- LX7II MID SUPPORT P-S2013D-02
--- LX7II 32IP FRONT PNL P-S2015A-06
--- LX7II I/P PCB ASSY R-S2011A-03-AF
--- LX7II MASTER+I/P PCB ASSY R-S2011C-04-AF
--- LX7II MASTER UPPER LINK PCB AS R-S2011G-01-AF
--- LX7II MASTER LOWER LINK PCB AS R-S2011H-01-AF
--- LX7II INPUT UPPER LINK PCB ASS R-S2011J-01-AF
--- LX7II INPUT LOWER LINK PCB ASS R-S2011K-01-AF
LX7II 32I/P REAR PNL ASSY RS2287
Ident Description Part Number
--- LX7II 32IP REAR PNL P-S2015B-03
--- LX7II RR CON PCB ASSY R-S2011B-02-AF
--- LX7II MASTER+RR CON PCB ASSY R-S2011D-02-AF
WIREFORMS USED IN THE FRAMES
Description Part Number Used in: (part number)
2MM 4WY CRIMP/CRIMP WFM-210MM RV4352-210 RS2282, RS2284, RS2286
2MM 6WY CRIMP/CRIMP WFM-160MM RV4353-160 RS2282, RS2284, RS2286
2MM 6WY CRIMP/CRIMP WFM-210MM RV4353-210 RS2282, RS2284, RS2286
2MM 8WY CRIMP/CRIMP WFM-530MM RV4354-530 RS2282, RS2284, RS2286
2MM 10WY CRIMP/CRIMP WFM 400MM RV4355-400 RS2282, RS2284, RS2286
2MM 10WY CRIMP/CRIMP WFM 600MM RV4355-600 RS2282, RS2284, RS2286
2MM 12WY CRIMP/CRIMP WFM-210MM RV4356-210 RS2282, RS2284, RS2286
LX7II PSU LINK WFM RV4357 R-S2011E-03-AF
