LX7-II Spare Parts Page 3 - 21
PCBS
LX7II I/P PCB SM ASSY R-S2011A-03-SM
Ident Description Part Number
--- LX7II I/P PCB S-S2011A-03
CA16 CAP CER 100NF 10% 50V X7R CS7104R-0805K
CA3,CB3 CAP CER 220PF 10% 50V X7R CS7221R-0805K
DA1,DB1 BAV70 SM DUAL DIODE COM CATH BS0013R-SOT23
ICA1 TL072CD SM DUAL OP AMP BS7001R-SO8
QA1,QA2 NPN TRANS BCW72 BS0502R-SOT23
R1 SM0805 RES 47K 1% 0.1W T200 AS0473R-0805F
R2 SM0805 RES 12K 1% 0.1W T200 AS0123R-0805F
R3 SM0805 RES 47K 1% 0.1W T200 AS0473R-0805F
R4 SM0805 RES 12K 1% 0.1W T200 AS0123R-0805F
R7 SM0805 RES 5K1 1% 0.1W T200 AS0512R-0805F
R8 SM0805 RES 3K9 1% 0.1W T200 AS0392R-0805F
R9 SM0805 RES 5K1 1% 0.1W T200 AS0512R-0805F
R10 SM0805 RES 3K9 1% 0.1W T200 AS0392R-0805F
RA1 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RA2 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RA3 SM0805 RES 82K 1% 0.1W T200 AS0823R-0805F
RA4 SM0805 RES 82K 1% 0.1W T200 AS0823R-0805F
RA6 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RA7 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RA8 SM0805 RES 68K 1% 0.1W T200 AS0683R-0805F
RA9 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RA10 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RA11 SM0805 RES 8K2 1% 0.1W T200 AS0822R-0805F
RA12 SM0805 RES 8K2 1% 0.1W T200 AS0822R-0805F
RA13 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RA14 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RA15 SM0805 RES 8K2 1% 0.1W T200 AS0822R-0805F
RA16 SM0805 RES 8K2 1% 0.1W T200 AS0822R-0805F
RA17 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RA18 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RA19 SM0805 RES 3K3 1% 0.1W T200 AS0332R-0805F
RA20 SM0805 RES 3K3 1% 0.1W T200 AS0332R-0805F
RA21 SM0805 RES 39K 1% 0.1W T200 AS0393R-0805F
RA22 SM0805 RES 68K 1% 0.1W T200 AS0683R-0805F
RA23 SM0805 RES 51K 1% 0.1W T200 AS0513R-0805F
RA24 SM0805 RES 27K 1% 0.1W T200 AS0273R-0805F
RA25 SM0805 RES 47K 1% 0.1W T200 AS0473R-0805F
RA26 SM0805 RES 12K 1% 0.1W T200 AS0123R-0805F
RA27 SM0805 RES 12K 1% 0.1W T200 AS0123R-0805F
RA28 SM0805 RES 12K 1% 0.1W T200 AS0123R-0805F
RA29 SM0805 RES 12K 1% 0.1W T200 AS0123R-0805F
RA30 SM0805 RES 12K 1% 0.1W T200 AS0123R-0805F
RA31 SM0805 RES 12K 1% 0.1W T200 AS0123R-0805F
RA32 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RA33 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RA34 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RA35 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RA36 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RA37 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RA38 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RA39 SM0805 RES 75R 1% 0.1W T200 AS0750R-0805F
RA40 SM0805 RES 4K7 1% 0.1W T200 AS0472R-0805F
RA41 SM0805 RES 10K 1% 0.1W T200 AS0103R-0805F
RA42 SM0805 RES 220K 1% 0.1W T200 AS0224R-0805F
RA43 SM0805 RES 22K 1% 0.1W T200 AS0223R-0805F
RA44 SM0805 RES 22K 1% 0.1W T200 AS0223R-0805F
RA45 SM0805 RES 470K 1% 0.1W T200 AS0474R-0805F
RA46 SM0805 RES 2K2 1% 0.1W T200 AS0222R-0805F
RA47 SM0805 RES 22K 1% 0.1W T200 AS0223R-0805F
RB1 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RB10 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RB11 SM0805 RES 8K2 1% 0.1W T200 AS0822R-0805F
RB12 SM0805 RES 8K2 1% 0.1W T200 AS0822R-0805F
RB13 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
