LX7-II Spare Parts Page 3 - 19
C42 CAP ELEC VERT 330MF 6.3V SKP 6 CE0455
C46 CAP ELEC VERT L-L 10UF 25V TPD CE0417
C49 CAP ELEC VERT L-L 10UF 25V TPD CE0417
C52 CAP ELEC VERT L-L 10UF 25V TPD CE0417
C55 CAP ELEC VERT L-L 10UF 25V TPD CE0417
CA9 CAP ELEC VERT 47UF 63V SKP 0.2 CE0402
CA10 CAP ELEC VERT 47UF 63V SKP 0.2 CE0402
CA11 CAP ELEC VERT 1000MF 6.3V SKP CE0433
CA12 MICRO-BOX 5MM 5% 470NF 63/100V CC0267
CA13 MICRO-BOX 5MM 5% 63V 33N CC0247
CA14 MICRO-BOX 5MM 5% 63V 33N CC0247
CA16 CAP ELEC VERT 33UF 16V SSP CE0457
CN1 8WY 2MM L/PRF VERT LCKG ML HDR FF1020
CN2 6WY 2MM L/PRF VERT LCKG ML HDR FF1019
CN3 12WY 2MM L/PRF VRT LCKG ML HDR FF1022
CN4 6WY 2MM L/PRF VERT LCKG ML HDR FF1019
CN5 10WY 2MM L/PRF VRT LCKG ML HDR FF1021
CN6 4WY 2MM L/PRF VERT LCKG ML HDR FF1018
CN7 6WY 2MM L/PRF VERT LCKG ML HDR FF1019
CN8 10WY 2MM L/PRF VRT LCKG ML HDR FF1021
Jack SLIMJACK METAL NOSE GOLD PIN FH0790
Jack JACK SKT STEREO 3PIN LIH SHENG FH0792
Jack JACK SKT STEREO 5PIN LIH SHENG FH0793
P2T DUAL PC PHONO VERT 24MM CLIFF FH0768
Pot ALPS 11MM 10KRD MIC DM1400
Q1 PNP TRANS 2SB737 LOW RBB BD0346
Q2 PNP TRANS 2SB737 LOW RBB BD0346
Q5 PNP TRANS 2SB737 LOW RBB BD0346
Q6 PNP TRANS 2SB737 LOW RBB BD0346
Q9 PNP TRANS 2SB737 LOW RBB BD0346
Q10 PNP TRANS 2SB737 LOW RBB BD0346
Q13 PNP TRANS 2SB737 LOW RBB BD0346
Q14 PNP TRANS 2SB737 LOW RBB BD0346
Q17 PNP TRANS 2SB737 LOW RBB BD0346
Q18 PNP TRANS 2SB737 LOW RBB BD0346
Q21 PNP TRANS 2SB737 LOW RBB BD0346
Q22 PNP TRANS 2SB737 LOW RBB BD0346
Q25 PNP TRANS 2SB737 LOW RBB BD0346
Q26 PNP TRANS 2SB737 LOW RBB BD0346
Q29 PNP TRANS 2SB737 LOW RBB BD0346
Q30 PNP TRANS 2SB737 LOW RBB BD0346
SA1 ALPS (SUN TYPE)2 POLE PUSH SWT DF0516
SB1 ALPS (SUN TYPE)2 POLE PUSH SWT DF0516
SC1 ALPS (SUN TYPE)2 POLE PUSH SWT DF0516
SD1 ALPS (SUN TYPE)2 POLE PUSH SWT DF0516
SE1 ALPS (SUN TYPE)2 POLE PUSH SWT DF0516
SF1 ALPS (SUN TYPE)2 POLE PUSH SWT DF0516
SG1 ALPS (SUN TYPE)2 POLE PUSH SWT DF0516
SH1 ALPS (SUN TYPE)2 POLE PUSH SWT DF0516
VR1 ALPS 14MM 2X5K RD DM1247
VR2 ALPS 14MM 2X5K RD DM1247
XLR XLR CON FML VERT FK0967-01
XLR XLR A-SRS PLASTIC ML PIN1 GND FK0970
LX7II MASTER UPPER LINK PCB AS R-S2011G-01-AF
Ident Description Part Number
--- LX7II MASTER UPPER LINK PCB S-S2011G-01
CN1 18WY VERT SIL HDR-SHORT PIN FF0806
CN2 18WY VERT SIL HDR-SHORT PIN FF0806
CN3 18WY VERT SIL HDR-SHORT PIN FF0806
CN4 18WY VERT SIL HDR-SHORT PIN FF0806
LX7II MASTER LOWER LINK PCB AS R-S2011H-01-AF
Ident Description Part Number
--- LX7II MASTER LOWER LINK PCB S-S2011H-01
CN1 18WY VERT SIL HDR-SHORT PIN FF0806
CN2 18WY VERT SIL HDR-SHORT PIN FF0806
