LX7-II Spare Parts Page 3 - 39
RG40 SM0805 RES 4K7 1% 0.1W T200 AS0472R-0805F
RG41 SM0805 RES 10K 1% 0.1W T200 AS0103R-0805F
RG42 SM0805 RES 220K 1% 0.1W T200 AS0224R-0805F
RG43 SM0805 RES 22K 1% 0.1W T200 AS0223R-0805F
RG45 SM0805 RES 470K 1% 0.1W T200 AS0474R-0805F
RG6 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RG7 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RG8 SM0805 RES 68K 1% 0.1W T200 AS0683R-0805F
RG9 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RH1 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RH10 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RH11 SM0805 RES 8K2 1% 0.1W T200 AS0822R-0805F
RH12 SM0805 RES 8K2 1% 0.1W T200 AS0822R-0805F
RH13 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RH14 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RH15 SM0805 RES 8K2 1% 0.1W T200 AS0822R-0805F
RH16 SM0805 RES 8K2 1% 0.1W T200 AS0822R-0805F
RH17 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RH18 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RH19 SM0805 RES 3K3 1% 0.1W T200 AS0332R-0805F
RH2 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RH20 SM0805 RES 3K3 1% 0.1W T200 AS0332R-0805F
RH21 SM0805 RES 39K 1% 0.1W T200 AS0393R-0805F
RH22 SM0805 RES 68K 1% 0.1W T200 AS0683R-0805F
RH23 SM0805 RES 51K 1% 0.1W T200 AS0513R-0805F
RH24 SM0805 RES 27K 1% 0.1W T200 AS0273R-0805F
RH25 SM0805 RES 47K 1% 0.1W T200 AS0473R-0805F
RH27 SM0805 RES 12K 1% 0.1W T200 AS0123R-0805F
RH28 SM0805 RES 12K 1% 0.1W T200 AS0123R-0805F
RH29 SM0805 RES 12K 1% 0.1W T200 AS0123R-0805F
RH3 SM0805 RES 82K 1% 0.1W T200 AS0823R-0805F
RH30 SM0805 RES 12K 1% 0.1W T200 AS0123R-0805F
RH31 SM0805 RES 12K 1% 0.1W T200 AS0123R-0805F
RH32 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RH33 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RH34 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RH35 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RH36 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RH37 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RH38 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RH4 SM0805 RES 82K 1% 0.1W T200 AS0823R-0805F
RH40 SM0805 RES 4K7 1% 0.1W T200 AS0472R-0805F
RH41 SM0805 RES 10K 1% 0.1W T200 AS0103R-0805F
RH42 SM0805 RES 220K 1% 0.1W T200 AS0224R-0805F
RH43 SM0805 RES 22K 1% 0.1W T200 AS0223R-0805F
RH45 SM0805 RES 470K 1% 0.1W T200 AS0474R-0805F
RH6 SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
RH7 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RH8 SM0805 RES 68K 1% 0.1W T200 AS0683R-0805F
RH9 SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
RR077 SM0805 RES 160K 1% 0.1W T200 AS0164R-0805F
TR1 PNP TRANS BCW70 BS0501R-SOT23
TR2 PNP TRANS BCW70 BS0501R-SOT23
TR3 PNP TRANS BCW70 BS0501R-SOT23
TR4 PNP TRANS BCW70 BS0501R-SOT23
TR5 PNP TRANS BCW70 BS0501R-SOT23
TR6 PNP TRANS BCW70 BS0501R-SOT23
LX7II MASTER+RR CON PCB SM AS R-S2011D-02-SM
Ident Description Part Number
SM0805 RES 75R 1% 0.1W T200 AS0750R-0805F
SM0805 RES 7K5 1% 0.1W T200 AS0752R-0805F
--- LX7II MASTER+RR CON PCB S-S2011D-02
C2 CAP CER 33PF 10% 100V CS1330R-0805K
C3 CAP CER 33PF 10% 100V CS1330R-0805K
C5 CAP CER 33PF 10% 100V CS1330R-0805K
C6 CAP CER 33PF 10% 100V CS1330R-0805K
C8 CAP CER 33PF 10% 100V CS1330R-0805K
C9 CAP CER 33PF 10% 100V CS1330R-0805K
C11 CAP CER 33PF 10% 100V CS1330R-0805K
C12 CAP CER 33PF 10% 100V CS1330R-0805K
C14 CAP CER 100PF 10% 100V CS1101R-0805K
