LX7-II Spare Parts Page 3 - 29
RG18 SM0805 RES 3K6 1% 0.1W T200 AS0362R-0805F
RG19 SM0805 RES 1K2 1% 0.1W T200 AS0122R-0805F
RG2 MMELF RES 6K8 1% 0.2W 50BLF AS2682R-0102F
RG20 SM0805 RES 24K 1% 0.1W T200 AS0243R-0805F
RG21 SM0805 RES 100K 1% 0.1W T200 AS0104R-0805F
RG22 SM0805 RES 75R 1% 0.1W T200 AS0750R-0805F
RG23 SM0805 RES 75R 1% 0.1W T200 AS0750R-0805F
RG24 SM0805 RES 75R 1% 0.1W T200 AS0750R-0805F
RG3 SM0805 RES 9K1 1% 0.1W T200 AS0912R-0805F
RG4 SM0805 RES 9K1 1% 0.1W T200 AS0912R-0805F
RG5 MMELF RES 1K2 1% 0.2W 50BLF AS2122R-0102F
RG6 MMELF RES 1K2 1% 0.2W 50BLF AS2122R-0102F
RG7 MMELF RES 1K2 1% 0.2W 50BLF AS2122R-0102F
RG8 MMELF RES 1K2 1% 0.2W 50BLF AS2122R-0102F
RG9 MMELF RES 1K2 1% 0.2W 50BLF AS2122R-0102F
RH1 MMELF RES 6K8 1% 0.2W 50BLF AS2682R-0102F
RH10 MMELF RES 1K2 1% 0.2W 50BLF AS2122R-0102F
RH11 MMELF RES 20K 1% 0.2W 50BLF AS2203R-0102F
RH12 MMELF RES 20K 1% 0.2W 50BLF AS2203R-0102F
RH13 MMELF RES 5K6 1% 0.2W 50BLF AS2562R-0102F
RH14 MMELF RES 5K6 1% 0.2W 50BLF AS2562R-0102F
RH15 SM0805 RES 10R 1% 0.1W T200 AS0100R-0805F
RH17 SM0805 RES 3K6 1% 0.1W T200 AS0362R-0805F
RH18 SM0805 RES 3K6 1% 0.1W T200 AS0362R-0805F
RH19 SM0805 RES 1K2 1% 0.1W T200 AS0122R-0805F
RH2 MMELF RES 6K8 1% 0.2W 50BLF AS2682R-0102F
RH20 SM0805 RES 24K 1% 0.1W T200 AS0243R-0805F
RH21 SM0805 RES 100K 1% 0.1W T200 AS0104R-0805F
RH22 SM0805 RES 75R 1% 0.1W T200 AS0750R-0805F
RH23 SM0805 RES 75R 1% 0.1W T200 AS0750R-0805F
RH24 SM0805 RES 75R 1% 0.1W T200 AS0750R-0805F
RH3 SM0805 RES 9K1 1% 0.1W T200 AS0912R-0805F
RH4 SM0805 RES 9K1 1% 0.1W T200 AS0912R-0805F
RH5 MMELF RES 1K2 1% 0.2W 50BLF AS2122R-0102F
RH6 MMELF RES 1K2 1% 0.2W 50BLF AS2122R-0102F
RH7 MMELF RES 1K2 1% 0.2W 50BLF AS2122R-0102F
RH8 MMELF RES 1K2 1% 0.2W 50BLF AS2122R-0102F
RH9 MMELF RES 1K2 1% 0.2W 50BLF AS2122R-0102F
LX7II MASTER+I/P PCB SM ASSY R-S2011C-04-SM
Ident Description Part Number
SM0805 RES 13K 1% 0.1W T200 AS0133R-0805F
SM0805 RES 15K 1% 0.1W T200 AS0153R-0805F
--- LX7II MASTER+I/P PCB S-S2011C-04
C2 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C3 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C4 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C8 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C9 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C10 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C14 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C15 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C16 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C20 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C21 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C22 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C26 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C27 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C28 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C32 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C33 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C34 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C37 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C38 CAP CER 10PF 5% 50V NPO CS1100R-0805J
C49 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C50 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C51 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C58 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C59 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C60 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C68 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
C69 CAP CER 22PF 5% 50V NP0 CS1220R-0805J
