3.0: INPUTS AND OUTPUTS
INPUTS, OUTPUTS, AND CONNECTIONS
3.0: INPUTS AND OUTPUTS
The physical inputs and outputs on the Notepad console are varied, and together with the mic
preampsandHi-Zinputcontrol,provideaexibleschemeforanysourcesyoumightencounter.Toget
the most out of the Notepad I/O, read this chapter carefully.
Console inputs can be used for a wide variety of sources. For best results always use the appropriate
input connection.
NOTEPAD 5, 8FX, 12FX User Manual
Analog Inputs
USB I/O
Analog Outputs

SoundCraft Notepad 12FX Specifications

General

Type	Analog Mixer
Channels	12
Mic Preamps	4
Aux Sends	1
USB	1 x USB Type B
Computer Connectivity	USB
EQ Bands	3-band EQ
Phantom Power	Yes
Inputs	12 (4 x Mono Mic/Line, 2 x Stereo Line, 2 x Stereo RCA)
Effects	Lexicon Effects (Reverb, Chorus, Delay)
