SoundCraft Notepad 12FX User Manual

5.1.2: STEREO INPUT CONTROLS
CHANNEL CONTROLS > STEREO PLAYBACK CONTROLS
5.1.2: STEREO INPUT CONTROLS
BAL
Adjust a stereo channel’s stereo weighting in the mix.
Balance aects only the signal’s position on the Master (MST) Left/Right output. The control adjusts the relative
levels of the left and right signals - eectively adjusting the left-right position of the overall stereo image. This
allows unbalanced stereo signals to be re-balanced to give the stereo signal desired.
Stereo Playback input channels, that sum the stereo RCA input and USB return signals, function simi-
lar to mono input channels with the following differences:
Aux / FX
Adjust the level of this channel’s contribution to the Aux/FX send bus
The Aux/FX controls on a stereo input channel work in the same way as for a mono input channel. The Aux bus is
stereo to allow for the output mode when headphones are attached to the Aux socket. The eects input however
is a mono sum.
NOTEPAD 5, 8FX, 12FX User Manual

SoundCraft Notepad 12FX Specifications

General

Type	Analog Mixer
Channels	12
Mic Preamps	4
Aux Sends	1
USB	1 x USB Type B
Computer Connectivity	USB
EQ Bands	3-band EQ
Phantom Power	Yes
Inputs	12 (4 x Mono Mic/Line, 2 x Stereo Line, 2 x Stereo RCA)
Effects	Lexicon Effects (Reverb, Chorus, Delay)
