SoundCraft Signature 12 User Manual

10, 12, 12MTK User Manual
4.3: FX RETURN
CONSOLE ROUTING > FX RETURN
4.3: FX RETURN ROUTING
An FX Return channel is a special stereo input channel is fed from the output of the internal FX
processor.
The FX Return channel can contribute to the Aux 1 and Aux 2 busses (NOT to Aux 3/FX as this
would cause a positive feedback loop), and to the Master and Group (Signature 12 and 12MTK only)
busses - as per mono and stereo input channels.

SoundCraft Signature 12 Specifications

General

Number of Channels	12
USB Interface	2-in/2-out
Faders	60mm
Phantom Power	Yes
Type	Analog
Headphone Output	1 x 1/4"
EQ Bands	3-band
Effects	Yes, with Lexicon effects
Inputs - Line	8
Outputs - Main	2 x XLR
Main Outputs	2
Monitor Outputs	1/4"
Weight	14.3 lbs
