SoundCraft Signature 12 User Manual

10, 12, 12MTK User Manual
8.3: DELAYS & MODULATION
LEXICON FX > DELAYS & MODULATION
8.3: DELAYS & MODULATION
Delaysrepeatasoundashorttimeafteritrstoccurs.Delaybecomesechowhentheoutputisfed
back into the input (feedback). This turns a single repeat into a series of repeats, each a little softer
than the last.
Modulationeffectsusealowfrequencyoscillatortovaryfrequency,amplitude,andlterparameters
over time.
SLAP (KARAOKE)
Slap echo is a distinctive vocal echo eect heard in classic Rock n Roll, Rockabilly, and other 'classic' genres, hence
its popularity in Karaoke!
Parameter 1: Number Of Repeats
Parameter 2: Delay Time
DELAY (2 SEC)
Basic delay algorithm with up to two seconds delay time.
Parameter 1: Number Of Repeats
Parameter 2: Delay Time
DELAY MOD
The modulated delay is enhanced by an LFO (low frequency oscillator) that produces a chorusing eect on the
delay repeats. This is a great delay for guitar and instrument passages that need that “special something.”
Parameter 1: Number Of Repeats
Parameter 2: Delay Time
TAPE
In the days before digital, tape echoes were created using a special tape recorder in which the magnetic recording
tape was looped, with closely-spaced recording and playback heads. The delay eect was created by the tape
moving in the space between the record and playback heads – while delay time was adjusted by changing the
speed of the tape loop. Although very musical-sounding, wow and flutter combined with a significant loss of high
frequencies, and to some extent also low frequencies, are all elements commonly associated with tape echo.
Parameter 1: Number Of Repeats
Parameter 2: Delay Time

SoundCraft Signature 12 Specifications

General

Number of Channels	12
USB Interface	2-in/2-out
Faders	60mm
Phantom Power	Yes
Type	Analog
Headphone Output	1 x 1/4"
EQ Bands	3-band
Effects	Yes, with Lexicon effects
Inputs - Line	8
Outputs - Main	2 x XLR
Main Outputs	2
Monitor Outputs	1/4"
Weight	14.3 lbs
